1967 1968 V700 Carburetor Control Cables Air Cleaner
| Position | Part Number | Description |
|---|---|---|
| 10 | 12112400 | Carburetor, R/H (#12112400) |
| 10 | 12112401 | Carburetor, L/H (#12112401) |
| 10 | 13112400 | 13112602 (#13112400) |
| 10 | 13112401 | 13112603 (#13112401) |
| 11 | ||
| 12 | 12607500 | CABLE THROTTLE (#12607500) |
| 13 | ||
| 14 | 12807100 | JUNCTION BLOCK COVER (#12807100) |
| 15 | ||
| 16 | 12807200 | JUNCTION BLOCK COVER (#12807200) |
| 17 | 98108015 | BOLT (#98108015) |
| 18 | 95101231 | FLAT WASHER (#95101231) |
| 19 | 92602208 | NUT (#92602208) |
| 20 | 95790232 | 95790233 (#95790232) |
| 21 | 92700071 | NUT (#92700071) |
| 22 | 12608300 | CABLE CHOKE ELDO,AMB,V700 (#12608300) |
| 23 | 12117000 | CHOKE CABLE, LOWER (#12117000) USE 12117001 |
| 24 | ||
| 25 | ||
| 26 | 12935300 | CAP (#12935300) |
| 27 | 12935400 | SCREW (#12935400) |
| 28 | 12935800 | NUT (#12935800) |
| 29 | 12935200 | ADJUSTER (#12935200) |
| 30 | ||
| 31 | 12935000 | CARB COVER (#12935000) |
| 32 | 12937100 | SPRING (#12937100) |
| 33 | 55938585 | NEEDLE CLIP (#55938585) |
| 34 | 12937500 | SLIDE #100 (#12937500) |
| 35 | 12937700 | SLIDE NEEDLE M14 (#12937700) |
| 36 | 12937000 | CHOKE (#12937000) |
| 37 | 12938600 | SCREW (#12938600) |
| 38 | 12938700 | CLAMP (#12938700) |
| 39 | 12937200 | CABLE ADJUSTER (#12937200) |
| 40 | ||
| 41 | 12937400 | PLUG (#12937400) |
| 42 | 12937600 | SPRING (#12937600) |
| 43 | 12937800 | AIR VALVE (#12937800) |
| 44 | 12937900 | CLOSE NIPPLE (#12937900) |
| 45 | 12938000 | PLUG - SLIDE (#12938000) |
| 45 | 12938801 | ACCELORATOR PUMP (#12938801) |
| 46 | ||
| 47 | 12932000 | BODY (#12932000) |
| 48 | ||
| 49 | 12933100 | PLUG (#12933100) |
| 50 | 12933000 | FLOATS SSI (#12933000) |
| 51 | 12933200 | NEEDLE X6 (#12933200) |
| 52 | 12932100 | ***COVER***N/A (#12932100) |
| 53 | 55932585 | CLIP (#55932585) |
| 54 | 12932400 | SPRING (#12932400) |
| 55 | 12934900 | TICKLER (#12934900) |
| 56 | 55934985 | PLUG (#55934985) |
| 57 | 55934785 | WASHER (#55934785) |
| 58 | 55934085 | PETROL FILTER NLA (#55934085) |
| 60 | 13935700 | MAIN JET (#13935700) USE 1486145 |
| 61 | 12934600 | ADAPTER (BANJO) (#12934600) |
| 62 | 12935700 | MAIN JET (#12935700) |
| 63 | 12938800 | JET HOLDER (#12938800) |
| 64 | ||
| 65 | 12936000 | GASKET (#12936000) |
| 66 | ||
| 67 | 12936300 | SPRING (#12936300) |
| 68 | 12113200 | AIR CLEANER BOX NLA (#12113200) |
| 69 | 12113600 | AIR FILTER (#12113600) |
| 70 | 12113400 | COVER (#12113400) |
| 71 | 98024312 | BOLT (#98024312) |
| 72 | 95021106 | WASHER, WAVE (#95021106) |
| 73 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 74 | 92602206 | NUT (#92602206) USE STHN6MM |
| 75 | 12114300 | RUBBER SLEEVE (#12114300) |
