1967 1968 V700 Oil Pump Oil Lines Filter Breather Unit Oil Pressure Solenoid
| Position | Part Number | Description |
|---|---|---|
| 10 | 12007200 | BREATHER TUBE (#12007200) |
| 11 | 12007600 | OIL RETURN GASKET (#12007600) |
| 12 | 98106015 | BOLT (#98106015) |
| 13 | 95021106 | WASHER, WAVE (#95021106) |
| 14 | 12006200 | OIL RETURN LINE (#12006200) USE 17006250 |
| 15 | 12006500 | BAND (#12006500) |
| 16 | 12006600 | SCREW (#12006600) |
| 17 | 90714124 | PETCOCK GASKET (#90714124) |
| 18 | 12158400 | OIL PIPE (#12158400) |
| 19 | 12159100 | GASKET (#12159100) |
| 20 | 98054430 | BOLT (#98054430) USE 98052430 |
| 21 | ||
| 22 | 12159000 | PLUG (#12159000) |
| 23 | 12006400 | ALUM CRUSH WASHER (#12006400) |
| 23 | 95100507 | WASHER (#95100507) |
| 23 | 95100522 | WASHER (#95100522) |
| 24 | 12150700 | BOTTOM PLATE (#12150700) |
| 25 | 94321070 | SPRING (#94321070) |
| 25 | 94321072 | SPRING (#94321072) |
| 26 | 12150900 | PISTON (#12150900) |
| 27 | 12146200 | OIL PUMP 13146201 (#12146200) |
| 27 | 13146200 | OIL PUMP (#13146200) USE 30146400 |
| 28 | 12147800 | SHAFT (#12147800) |
| 29 | 12148500 | GEAR (#12148500) |
| 30 | 12147700 | GEAR (#12147700) |
| 30 | 13147700 | GEAR (#13147700) |
| 31 | 91701232 | OIL PUMP KEY (#91701232) |
| 32 | 95101231 | FLAT WASHER (#95101231) |
| 33 | 92701086 | NUT*NLA* (#92701086) |
| 34 | 98108042 | BOLT (#98108042) |
| 35 | 98022455 | BOLT (#98022455) |
| 36 | 12149800 | LOCK PLATE (#12149800) |
| 37 | 12152200 | OIL CLEANER (#12152200) |
| 38 | 12153000 | WIRE GAUZE (#12153000) |
| 39 | 12152600 | BOTTOM PLATE (#12152600) |
| 40 | 98024310 | SCREW (#98024310) |
| 41 | 12157500 | TUBE(#12157500) USE 00823956080 |
| 42 | 12153200 | GASKET (#12153200) |
| 43 | 95021108 | WASHER (#95021108) |
| 44 | 98020435 | BOLT (#98020435) |
| 45 | 12153600 | PIPE OIL FEED LINE (#12153600) |
| 46 | 12154200 | OIL LINE CRUSH WASHER (#12154200) |
| 46 | 90714082 | FIBER WASHER USE 1215 4200 CRUSH WASHER (#90714082) |
| 47 | 95990035 | BANJO BOLT (#95990035) |
| 47 | 95990037 | BANJO BOLT (#95990037) |
| 48 | 12768700 | OIL SENDING UNIT (#12768700) USE 17768750 |
| 49 | 12157600 | TUBE (#12157600) USE 95985136 |
| 50 | 12155700 | OIL BREATHER USE 1215 5701 (#12155700) |
| 51 | 12157400 | BREATHER TUBE (#12157400) USE 14157400 |
