1969 1972 750 Ambassador Carburetor Control Cables Air Cleaner
| Position | Part Number | Description |
|---|---|---|
| 10 | 13112402 | USE 13112602 (#13112402) |
| 10 | 13112403 | USE 13112603 (#13112403) |
| 11 | 12114401 | TUBE OR VOLICITY STACK (#12114401) |
| 12 | 12607500 | CABLE THROTTLE (#12607500) |
| 13 | 12607900 | ADAPTER (#12607900) |
| 14 | 12807100 | JUNCTION BLOCK COVER (#12807100) |
| 15 | 12807000 | PLUNGER (#12807000) |
| 16 | 12807200 | JUNCTION BLOCK COVER (#12807200) |
| 17 | 98108015 | BOLT (#98108015) |
| 18 | 95101231 | FLAT WASHER (#95101231) |
| 19 | 92602208 | NUT (#92602208) |
| 20 | 95790233 | SCREW (#95790233) |
| 21 | 92700071 | NUT (#92700071) |
| 22 | 12608300 | CABLE CHOKE ELDO,AMB,V700 (#12608300) |
| 23 | 12117001 | CABLE CHOKE LOWER V700/AMB/ELD (#12117001) |
| 24 | 12117501 | THROTTLE CABLE V700,AMB,ELDO (#12117501) |
| 25 | 13937000 | PROTECT CAP CABLE BOOT (#13937000) |
| 26 | 13932800 | SCREW NLA (#13932800) |
| 26 | 13932900 | WASHER (#13932900) |
| 27 | 12937200 | CABLE ADJUSTER (#12937200) |
| 28 | 12937300 | NUT (#12937300) |
| 29 | 13935000 | COVER (#13935000) |
| 30 | 13937100 | SPRING (#13937100) |
| 31 | 13937500 | VALVE SQUARE SLIDE (#13937500) |
| 32 | 13937700 | V5 Needle VHB Carb (#13937700) |
| 33 | 55938585 | NEEDLE CLIP (#55938585) |
| 34 | 13937900 | SCREW (#13937900) |
| 35 | 13937400 | CUP (#13937400) |
| 36 | 13937600 | SPRING (#13937600) |
| 37 | 13937800 | VALVE CHOKE (#13937800) |
| 38 | 13933700 | CARB BOWL NUT (#13933700) |
| 39 | 13933400 | O RING for Float Bowl (#13933400) |
| 39 | 13933900 | WASHER (#13933900) |
| 39 | 13934400 | BODY (#13934400) |
| 40 | 13933000 | FLOAT (#13933000) USE 14933000 |
| 41 | 13933100 | FLOAT PIN (13933100) (#13933100) |
| 42 | 13934800 | FLOAT NEEDLE VALVE (#13934800) |
| 43 | 13935700 | MAIN JET (#13935700) USE 1486145 |
| 44 | 13938800 | PUMP HOLDER NO LONGER AVAILABLE AS OF 1997 (#13938800) |
| 45 | 13935500 | ATOMIZER #265 FOR VHB (#13935500) |
| 46 | 13935900 | 148645 (#13935900) |
| 47 | 13936000 | START JET #80 (#13936000) |
| 47 | 13936100 | O RING (#13936100) |
| 48 | 13936600 | SCREW (#13936600) |
| 49 | 13936700 | SPRING (#13936700) |
| 50 | 13936200 | SCREW (#13936200) |
| 51 | 13936300 | SPRING (#13936300) |
| 52 | 13936800 | NUT (#13936800) |
| 53 | 13938600 | SCREW CAN USE 14938600 (#13938600) |
| 54 | 13938700 | CLAMP (13938700) (#13938700) |
| 55 | 13938900 | INSULATOR (#13938900) |
| 56 | 13934900 | BOLT (#13934900) USE 10934900 |
| 57 | 13934700 | FIBER WASHERS (#13934700) |
| 58 | 13934600 | CARB.ADAPTER BLACK PLASTIC (#13934600) |
| 59 | 43934000 | Fuel Filter Screen (43934000) (#43934000) |
| 60 | 12113200 | AIR CLEANER BOX NLA (#12113200) |
| 61 | 12113600 | AIR FILTER (#12113600) |
| 62 | 12113401 | COVER (#12113401) |
| 63 | 98024312 | BOLT (#98024312) |
| 64 | 95021106 | WASHER, WAVE (#95021106) |
| 65 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 66 | 92602206 | NUT (#92602206) USE STHN6MM |
| 67 | 12114301 | SLEEVE, CARB (#12114301) |
