1976 1981 1000 Convert Handle Bar Controls Instrument Panel
| Position | Part Number | Description |
|---|---|---|
| 1 | 17600320 | HANDLEBAR 850T, T3, G5, V1000 CONVERT STANDARD (#17600320) |
| 2 | 18769150 | INST. PANEL (#18769150) USE 18769120 |
| 3 | 18765250 | LOWER PART INST. (#18765250) USE 18765251 |
| 4 | ||
| 5 | 93450140 | BULB (93450140) (#93450140) USE 164634 |
| 6 | 18766850 | PLUG (#18766850) |
| 7 | 98260525 | SCREW CHROME (#98260525) |
| 8 | 13745740 | SWITCH (#13745740) |
| 9 | 18761500 | SPEEDOMETER KPH (#18761500) |
| 10 | 12760400 | SPEEDO CABLE (#12760400) |
| 11 | 18763350 | SPEEDOMETER DRIVE (#18763350) |
| 12 | 18766150 | GEAR RING (#18766150) |
| 13 | 17762200 | RUBBER BOOT (#17762200) |
| 14 | 13760643 | LAMP SOCKET (#13760643) |
| 15 | 13762143 | LAMP (#13762143) |
| 16 | 95100463 | WASHER (#95100463) |
| 17 | 10502250 | BUSH NLA (#10502250) |
| 18 | 95000208 | WASHER (#95000208) |
| 19 | 98622416 | SCREW (#98622416) |
| 20 | 14603500 | RH GRIP (#14603500) |
| 21 | 17603400 | TOMMASELLI DUAL THROTTLE ASSY. (#17603400) |
| 22 | 17604850 | BELLOWS (#17604850) |
| 23 | 17735000 | SWITCH NLA (#17735000) USE 120030 or 120040. |
| 24 | 17755800 | COVER FOR SWITCH (#17755800) |
| 25 | 14603000 | GRIP (#14603000) USE1137800 |
| 26 | 17751100 | RING (#17751100) |
| 27 | ||
| 28 | 14746020 | SWITCH (#14746020) NLA USE 120030 |
| 29 | 14755700 | (#14755700) USE 17755700 |
| 30 | 17605550 | CL. LEVER COMPLETE 11760 5550 use 17605570 (#17605550) |
| 31 | 17605750 | CLUTCH LEVER (#17605750) |
