1976 1981 1000 G5 Ignition Kits
| Position | Part Number | Description |
|---|---|---|
| 1 | 18712450 | ALTERNATOR (#18712450) |
| 2 | 98620245 | SCREW (#98620245) |
| 3 | 95021105 | LOCK WASHER (#95021105) |
| 4 | ||
| 5 | ||
| 6 | 17718450 | (#17718450) USE 061079 |
| 7 | 14717600 | SPARK PLUG RUBBER BOOT (#14717600) |
| 8 | ||
| 9 | 17717050 | 18717050 (#17717050) |
| 9 | 18717050 | SPARK PLUG (#18717050) |
| 9 | 25717025 | Spark plug (#25717025) |
| 10 | 14716500 | COIL NLA FROM MOTO (#14716500) USE DC10-1 |
| 11 | 14747700 | CABLE (#14747700) |
| 12 | 98052345 | SCREW (#98052345) |
| 13 | 95100141 | WASHER (#95100141) |
| 14 | 93110060 | RUBBER WASHER (#93110060) |
| 15 | 91180718 | SPACER (#91180718) |
| 16 | 95100154 | SPACER RING (#95100154) |
| 17 | 95000206 | WASHER (#95000206) |
| 18 | 92630106 | NUT USE 92630707 (#92630106) |
| 19 | 98054320 | BOLT (#98054320) |
| 20 | 92602206 | NUT (#92602206) USE STHN6MM |
| 21 | 17716850 | SUPPORT (#17716850) |
| 22 | 98052325 | BOLT (#98052325) |
| 23 | 98054416 | BOLT (#98054416) |
| 24 | 95004208 | WASHER (#95004208) |
| 25 | 95021108 | WASHER (#95021108) |
| 26 | 92602208 | NUT (#92602208) |
| 27 | 17703800 | VOLTAGE REGULATOR (#17703800) use 040003 |
| 28 | 98054312 | BOLT (#98054312) |
| 29 | 95021106 | WASHER, WAVE (#95021106) |
| 30 | 18736801 | IGN. SWITCH (#18736801) |
| 31 | 18736401 | IGNITION SWITCH BRACKET (#18736401) |
| 32 | 19735300 | IG SWITCH USE 31735360 (#19735300) |
| 33 | 95100059 | WASHER (#95100059) |
| 34 | 19733350 | COVER, SOLENOID NLA 7/15/02 (#19733350) |
| 35 | ||
| 36 | 14704205 | Cover (#14704205) |
| 37 | 98305017 | SCREW (#98305017) |
| 38 | 95000205 | WASHER (#95000205) |
| 39 | 92602205 | NUT (#92602205) |
| 40 | 17748500 | CABLE (#17748500) |
| 41 | 17747850 | WIRE (#17747850) |
| 42 | 14704505 | BATTERY COVER (#14704505) |
| 43 | 14707000 | BATTERY TRAY (#14707000) |
| 44 | 14704800 | BATTERY STRAP (#14704800) |
| 45 | 14705500 | BATTERY STRAP, REAR (#14705500) |
| 46 | 93180220 | TIMING HOLE PLUG (#93180220) |
| 47 | 14748400 | BATTERY CABLE NEGATIVE NLA (#14748400) |
| 48 | ||
| 49 | 25706700 | DUST COVER (#25706700) |
| 50 | 19707100 | CAP (#19707100) |
| 51 | ||
| 52 | 98054214 | BOLT (#98054214) |
| 53 | 14730706 | STARTER MOTOR {USE 30730711 VALEO STARTER) (#14730706) |
| 54 | 14730558 | SOLENOID SEE 1473 0558A (#14730558) |
| 55 | 14730570 | REV.KIT (#14730570) |
| 56 | 92630108 | NUT 8MM (#92630108) |
| 57 | 98052485 | BOLT (#98052485) |
| 58 | 17715450 | DISTRIBUTOR REGULATOR (#17715450) |
| 59 | ||
| 60 | 14716400 | DISTRIBUTOR BASE GASKET (#14716400) |
| 61 | 95510318 | PIN (#95510318) |
| 62 | 14716200 | GEAR (#14716200) |
| 63 | 14715700 | PLATE (#14715700) |
| 64 | 98052430 | BOLT (#98052430) |
| 65 | 95120085 | WASHER (#95120085) |
| 66 | 91180907 | SPACER (#91180907) |
| 67 | 17929900 | TOOL KIT 28929940 (#17929900) |
| 68 | 18900000 | Riders Handbook (Italian) (#18900000) |
| 68 | 18900001 | G5 Owners Manual (#18900001) |
| 69 | ||
| 70 | 61712500 | CONNECTOR (#61712500) |
| 71 | 61712600 | CONNECTOR (#61712600) |
