1976 1981 1000 G5 Rear Fork And Transmission
| Position | Part Number | Description |
|---|---|---|
| 1 | 18540200 | FORK (#18540200) |
| 2 | 98062535 | BOLT (#98062535) |
| 3 | 95005210 | WASHER (#95005210) |
| 4 | 14547800 | NUT (#14547800) |
| 5 | 12547200 | SPACER (#12547200) |
| 6 | 14547001 | SWING ARM PIN (#14547001) |
| 7 | 90403040 | SEAL, REAR FORK SPINDLE (#90403040) |
| 8 | 92249216 | BEARING (#92249216) USE 92249217 |
| 9 | 18548000 | U JOINT BOOT (#18548000) |
| 10 | 12548401 | CLAMP (#12548401) USE 93306050 |
| 11 | ||
| 12 | 17328050 | U JOINT (#17328050) |
| 13 | 90272062 | CIRCLIP (#90272062) |
| 14 | 92204230 | BEARING (#92204230) |
| 15 | 12555201 | BOTTOM PIN (#12555201) |
| 16 | 17350250 | TRANS COMPLETE USE 2935 0250 (#17350250) |
| 17 | 17350300 | TRANS. HOUSING USE 2935 0350 (#17350300) |
| 18 | 98508045 | Stud (#98508045) |
| 19 | 14615901 | WASHER (#14615901) |
| 20 | 92781081 | CAP NUT (#92781081) USE STCN8MM |
| 21 | 12003702 | DRAIN PLUG MAGNETIC (#12003702) |
| 22 | 95100709 | CRUSH WASHER (95100709) (#95100709) |
| 23 | 95980610 | PLUG (#95980610) |
| 24 | 10528900 | CRUSH WASHER, COPPER (#10528900) |
| 25 | 90403850 | SEAL (#90403850 ) |
| 26 | 12351100 | RING COPPER METAL SPACER (#12351100) |
| 27 | ||
| 28 | 12326300 | SHAFT (#12326300) |
| 29 | 12327700 | SLEEVE (#12327700) |
| 30 | 90271020 | CIRCLIP (#90271020) |
| 31 | 12356700 | LOCK NUT (#12356700) |
| 32 | 92249227 | BEARING (#92249227) |
| 33 | 18352400 | FLANGE (#18352400) |
| 34 | 90706584 | O RING (#90706584) |
| 35 | 18355100 | SPACER (#18355100) |
| 36 | 12355202 | SHIM 0.10MM (#12355202) |
| 36 | 12355203 | SHIM 0.15MM (#12355203) |
| 37 | 12355301 | SHIM 1.0MM (#12355301) |
| 37 | 12355302 | SHIM 1.2MM (#12355302) |
| 37 | 12355303 | SPACER (#12355303) |
| 38 | 98054425 | BOLT (#98054425) |
| 39 | 61270300 | WASHER (#61270300) |
| 40 | 95187008 | LOCK PLATE (#95187008) USE 1461 5901 |
| 41 | 17350400 | FLANGE (#17350400) |
| 42 | 17350700 | DIFFERENTIAL BEARING GASKET (#17350700) |
| 43 | 17355400 | SHIM 0.8MM (#17355400) |
| 43 | 17355402 | SHIM 0.9MM (#17355402) |
| 43 | 17355404 | SHIM 1.0MM (#17355404) |
| 43 | 17355406 | SHIM 1.1MM (#17355406) |
| 43 | 17355408 | SHIM 1.2MM (#17355408) |
| 43 | 17355410 | SHIM 1.3MM (#17355410) |
| 44 | 92201070 | BEARING (#92201070) |
| 45 | 90407085 | REAR DRIVE SEAL OUTPUT TO WHEEL (90407085) USE 9041 7085 (#90407085) |
| 46 | 17351400 | DRIVE FLANGE OR HUB NLA USE 1735 1401* (#17351400) |
| 47 | 17354650 | BEVEL GEAR 7/33 (#17354650) |
| 48 | 12356300 | SCREW (#12356300) |
| 49 | 12356400 | PLATE (#12356400) |
