1983 1986 California II 1000 Lh Front Brake System
| Position | Part Number | Description |
|---|---|---|
| 1 | 17658550 | FRONT BRAKE HOSE (#17658550) |
| 1 | 18658560 | BRAKE HOSE (#18658560) |
| 2 | 95990028 | SCREW (#95990028) |
| 3 | 25656100 | WASHER, ALUMINUM (#25656100) |
| 4 | 28668145 | BRAKE ADAPTER (#28668145) |
| 5 | 95021106 | WASHER, WAVE (#95021106) |
| 6 | 92602206 | NUT (#92602206) USE STHN6MM |
| 7 | 12735100 | CAP (#12735100) |
| 8 | 92602208 | NUT (#92602208) |
| 9 | 29667000 | MASTER CYL REAR (#29667000) |
| 10 | 95021108 | WASHER (#95021108) |
| 11 | 95129130 | SHAKE PROOF WASHER (#95129130) |
| 12 | 95100173 | WASHER (#95100173) |
| 13 | 95500222 | SPLIT PIN (#95500222) |
| 14 | 92630206 | NUT (#92630206) |
| 15 | 95000206 | WASHER (#95000206) |
| 16 | 17667550 | CONTROL LEVER (#17667550) |
| 17 | 98620440 | SCREW (#98620440) |
| 18 | ||
| 19 | 93301313 | BRACKET (#93301313) |
| 20 | 14661100 | CAP (#14661100) |
| 21 | 91551120 | GROMMET (#91551120) |
| 23 | 98622530 | BOLT (#98622530) |
| 24 | 95004210 | WASHER (#95004210) |
| 25 | 18635860 | BRACKET (#18635860) |
| 26 | 17658750 | PIPE (#17658750) |
| 27 | 17659650 | TUBE (#17659650) |
| 28 | 14609650 | TIE WRAP (#14609650) |
| 29 | 90716142 | SLEEVE (#90716142) |
| 30 | 98054314 | SCREW (#98054314) |
| 31 | 17658650 | PIPE (#17658650) |
| 32 | 18653060 | F09 CALIPER SP 1 (#18653060) |
| 32 | 28652301 | CALIPER RH (#28652301) |
| 33 | 92630106 | NUT USE 92630707 (#92630106) |
| 34 | 14658851 | PIPE (#14658851) |
| 35 | 63657000 | BRAKE LIGHT SWITCH (#63657000) |
| 36 | 98054320 | BOLT (#98054320) |
| 37 | ||
| 38 | 62436500 | BRACKET (#62436500) |
| 40 | 95100332 | SHIM 0.5 MM (#95100332) |
| 40 | 95100333 | SHIM 0.8 MM (#95100333) |
| 41 | 95129180 | WAVE WASHER (#95129180) |
| 42 | 92602210 | NUT (#92602210) |
| 44 | 28654601 | (#28654601) |
| 45 | 17654760 | COVER (#17654760) |
| 46 | 17659350 | Rear Master Cylinder Kit (Front for T) (#17659350) |
| 47 | 17659260 | BLEEDER SCREW KIT (#17659260) |
| 48 | 14659100 | BRAKE PINS KIT 2 PER BAG (#14659100) |
| 48 | 18659150 | PIN KIT (#18659150) |
| 49 | 14659000 | CALIPER KIT (#14659000) |
| 49 | 18659050 | CALIPER KIT (#18659050) |
| 50 | 28659750 | BRKTS (#28659750) |
| 51 | 28653001 | CALIPER (#28653001) |
| 52 | 98620540 | SCREW (#98620540) |
| 53 | 17747550 | WIRING HARNESS (#17747550) |
| 55 | 14659450 | REV.KIT (#14659450) |
| 56 | 14661300 | BELLOWS M/C REAR WAS 17661350 (#14661300) |
| 57 | 17667751 | #57 Bush (#17667751) |
