1983 1986 California II 1000 Oil Pump
| Position | Part Number | Description |
|---|---|---|
| 1 | 13146402 | PUMP (#13146402) |
| 2 | 13148400 | GEAR (#13148400) |
| 3 | 13147800 | PUMP GEAR (#13147800) |
| 4 | 13148300 | KEY SQUARE STOCK (#13148300) |
| 5 | 92252210 | BEARING (#92252210) |
| 6 | ||
| 7 | 92602308 | NUT (#92602308) |
| 8 | 95120085 | WASHER (#95120085) |
| 9 | 98622430 | SCREW (#98622430) |
| 10 | 14152200 | FILTER SCREEN (#14152200) |
| 11 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 12 | 95187006 | STOP PLATE (#95187006) |
| 13 | 14153000 | UFI OIL FILTER #14153000 (#14153000 ) |
| 14 | 14158200 | VALVE (#14158200) |
| 15 | 10158701 | VALVE HOUSING (#10158701) |
| 16 | 12150900 | PISTON (#12150900) |
| 17 | 94321072 | SPRING (#94321072) |
| 18 | 12150700 | BOTTOM PLATE (#12150700) |
| 19 | 12159000 | PLUG (#12159000) |
| 20 | 95100523 | WASHER (#95100523) |
| 21 | 14158800 | BOTTOM CUP (#14158800) |
| 22 | 17768750 | OIL SENDER (#17768750) |
| 23 | 12006400 | ALUM CRUSH WASHER (#12006400) |
| 24 | 12717600 | Cap (#12717600) |
| 25 | 01153600 | OIL FEED LINE USE 01153602 (#01153600) |
| 26 | 95990037 | BANJO BOLT (#95990037) |
| 27 | 12154200 | OIL LINE CRUSH WASHER (#12154200) |
| 28 | 25656102 | GASKET (#25656102) |
| 29 | 28157450 | PIPE-RUBBER HOSE (#28157450) |
| 30 | 12157800 | BAND OR CLAMP (#12157800) |
| 31 | 00823956080 | OIL BREATHER HOSE (#00823956080) |
| 32 | 28157950 | BREATHER PIPE CLAMP (#28157950) |
| 33 | 01007200 | VENT PIPE A (#01007200) |
| 36 | 12007600 | OIL RETURN GASKET (#12007600) |
| 39 | 95120065 | WASHER (#95120065) |
| 41 | 28150560 | CHECK VALVE (#28150560) |
| 42 | 12108400 | BAND (#12108400) |
| 43 | 28153960 | CONNECTOR A (#28153960) |
