1985 1987 V 35 III 350 Front Fork
| Position | Part Number | Description |
|---|---|---|
| 1 | 62494021 | HANDLEBAR BOTTOM PLATE (#62494021) |
| 2 | 17517700 | DISC 1415 6600 (#17517700) |
| 3 | 98072555 | BOLT BLACK (#98072555) |
| 4 | 95007210 | WASHER (#95007210) |
| 5 | 91181016 | SPACER (#91181016) |
| 6 | 62493200 | WASHER (#62493200) |
| 7 | 27493135 | Upper plate (#27493135) |
| 8 | 98610540 | BOLT (#98610540) |
| 9 | 98612535 | SCREW BLACK (#98612535) |
| 10 | 17516600 | BUSHING 1451 6600 (#17516600) |
| 11 | 27522535 | #11 RH slider (#27522535) |
| 12 | 27522635 | #12 LH slider (#27522635) |
| 13 | 90403449 | FORK SEAL (#90403449) |
| 14 | 27527620 | SLEEVE A (#27527620) |
| 15 | 9862232005 | #15 Screw (#9862232005) |
| 16 | 95100116 | WASHER (#95100116) |
| 17 | 27525420 | FORK TUBE B (#27525420) |
| 18 | 14524500 | FORK DUST COVERS (#14524500) |
| 19 | 27526420 | DAMPER A (#27526420) |
| 20 | 92602308 | NUT (#92602308) |
| 21 | 27527520 | BUFFER (#27527520) |
| 22 | 27526620 | LOWER SPRING (#27526620) |
| 23 | 98620545 | ALLEN BOLT (#98620545) |
| 24 | 98622525 | BOLT (#98622525) |
| 25 | 28556450 | SCREW (#28556450) |
| 26 | 28556250 | VALVE (#28556250) |
| 27 | 90706266 | O RING (#90706266) |
| 28 | 28556350 | WASHER SPECIAL PLASTIC WASHER (#28556350) |
| 29 | 19529660 | TUBE (#19529660) |
| 30 | 92781100 | CAP NUT CHROME (#92781100) |
| 31 | ||
| 32 | 27499120 | WASHER A (#27499120) |
| 33 | 27496185 | #33 RH slider (#27496185) |
| 34 | 27496285 | #34 LH slider (#27496285) |
| 36 | 90706094 | O RING-VITON (#90706094) |
| 37 | 27526320 | TUBE A (#27526320) |
| 38 | 17500200 | CLAMP (#17500200) |
| 39 | 96508045 | SCREW (#96508045) |
| 40 | 95021108 | WASHER (#95021108) |
| 41 | 92602208 | NUT (#92602208) |
| 42 | 92781081 | CAP NUT (#92781081) USE STCN8MM |
| 43 | 98052499 | BOLT (#98052499) |
| 44 | 95000208 | WASHER (#95000208) |
