1986 1990 V 35 Florida 350 Front Fork
| Position | Part Number | Description |
|---|---|---|
| 1 | 23494010 | #01 Lower plate (#23494010) |
| 2 | 18513560 | SHIM (#18513560) |
| 3 | 98072555 | BOLT BLACK (#98072555) |
| 4 | 95007210 | WASHER (#95007210) |
| 5 | 91181016 | SPACER (#91181016) |
| 6 | 18513460 | NUT (#18513460) |
| 7 | 27493135 | Upper plate (#27493135) |
| 8 | 98610540 | BOLT (#98610540) |
| 9 | 98612535 | SCREW BLACK (#98612535) |
| 10 | 18516660 | BUSHING (#18516660) |
| 11 | 23522510 | #11 RH sleeve (#23522510) |
| 12 | 23522610 | #12 LH sleeve (#23522610) |
| 13 | 90403449 | FORK SEAL (#90403449) |
| 14 | 27527620 | SLEEVE A (#27527620) |
| 15 | 98622325 | BOLT CHROME (#98622325) |
| 16 | 95100116 | WASHER (#95100116) |
| 17 | 23525410 | #17 Sleeve (#23525410) |
| 18 | 14524500 | FORK DUST COVERS (#14524500) |
| 19 | 23526410 | Shock absorber (#23526410) |
| 21 | 27527520 | BUFFER (#27527520) |
| 22 | 23526910 | #22 Spring (#23526910) |
| 23 | 98620540 | SCREW (#98620540) |
| 24 | 98622525 | BOLT (#98622525) |
| 25 | 28556450 | SCREW (#28556450) |
| 26 | 28556250 | VALVE (#28556250) |
| 27 | 90706266 | O RING (#90706266) |
| 28 | 28556350 | WASHER SPECIAL PLASTIC WASHER (#28556350) |
| 29 | 19529660 | TUBE (#19529660) |
| 30 | 92781100 | CAP NUT CHROME (#92781100) |
| 32 | 27499120 | WASHER A (#27499120) |
| 33 | 23496110 | RH H/L BRACKET (#23496110) |
| 34 | 23496210 | LH H/L BRKT A (#23496210) |
| 36 | 90706094 | O RING-VITON (#90706094) |
| 37 | 23527910 | SPACER (#23527910) |
| 38 | 92602308 | NUT (#92602308) |
| 39 | 14615901 | WASHER (#14615901) |
| 40 | 98620435 | SCREW USE 9868 0435 (#98620435) |
| 41 | 23500210 | HANDLEBAR CLAMP A (#23500210) |
| 42 | 23943410 | CHROME PLUG (#23943410) |
| 43 | 96508021 | STUD BOLT (#96508021) |
| 44 | 23497910 | SPACER (#23497910) |
| 45 | 98622425 | ALLEN BOLT (#98622425) |
| 46 | 23526610 | #20 Return spring (#23526610) |
| 47 | 27526320 | TUBE A (#27526320) |
| 48 | 27526685 | #22 Spring (#27526685) |
