1986 1992 V 65 Florida 650 Foot Rests Lateral Stand
| Position | Part Number | Description |
|---|---|---|
| 1 | 23420310 | #01 RH craddle arm (#23420310) |
| 2 | 23422110 | #02 LH craddle arm (#23422110) |
| 3 | 23430370 | #03 Central stand (#23430370) |
| 4 | 13432640 | CENTER STAND/SIDE STAND RUBBER (#13432640) |
| 5 | 12434001 | SPRING (#12434001) |
| 6 | 98054530 | BOLT (#98054530) |
| 7 | 91181114 | SPACER (#91181114) |
| 8 | 94322215 | SPRING-ROCKER (#94322215) |
| 9 | 95000210 | WASHER (#95000210) |
| 10 | 92630510 | NUT (#92630510) |
| 11 | 23432011 | #11 Lateral stand (#23432011) |
| 12 | 19433000 | PLUG (#19433000) |
| 13 | 99105129 | BOLT (#99105129) |
| 14 | 23434010 | #14 Spring (#23434010) |
| 15 | 95401215 | COTTER PIN (#95401215) |
| 16 | 92602210 | NUT (#92602210) |
| 17 | 98054322 | BOLT (#98054322) |
| 18 | 23440710 | RF FOOTPEG A (#23440710) |
| 19 | 23441810 | LF FOOTPEG A (#23441810) |
| 20 | 23441110 | SPRING (#23441110) |
| 21 | 23441210 | FOOTREST PLATE (#23441210) |
| 23 | 98054314 | SCREW (#98054314) |
| 24 | 23443210 | FOOTREST RUBBER (#23443210) |
| 25 | 95000208 | WASHER (#95000208) |
| 27 | 98052565 | BOLT (#98052565) |
| 28 | 95004210 | WASHER (#95004210) |
| 29 | 92602206 | NUT (#92602206) USE STHN6MM |
| 30 | 23442210 | PIVOT PIN A (#23442210) |
| 31 | 19017000 | BUSH (#19017000) |
| 32 | 53429500 | BOLT (#53429500) |
| 34 | 91180602 | SPACER (#91180602) |
| 35 | 95129130 | SHAKE PROOF WASHER (#95129130) |
| 36 | 18252050 | BUSH NLA (#18252050) USE 30678160 |
| 36 | 28252060 | BUSHING (#28252060) |
