1987 1993 California III Carbureted Swing Arm
| Position | Part Number | Description |
|---|---|---|
| 1 | 29540250 | REAR FORK C (#29540250) |
| 2 | 98052535 | BOLT (#98052535) |
| 3 | 95004210 | WASHER (#95004210) |
| 4 | 29547850 | NUT (#29547850) |
| 5 | 12547200 | SPACER (#12547200) |
| 6 | 14547001 | SWING ARM PIN (#14547001) |
| 7 | 90403040 | SEAL, REAR FORK SPINDLE (#90403040) |
| 8 | 92249217 | BEARING (#92249217) |
| 9 | 18548000 | U JOINT BOOT (#18548000) |
| 10 | 93305060 | CLAMP (#93305060) |
| 11 | 93305078 | REAR SWING ARM CLAMP (#93305078) |
| 12 | 30328031 | U-JOINT (#30328031) |
| 13 | 90272062 | CIRCLIP (#90272062) |
| 14 | 92204230 | BEARING (#92204230) |
| 15 | 29326300 | SHAFT (#29326300) |
| 16 | 12327700 | SLEEVE (#12327700) |
| 17 | 90271020 | CIRCLIP (#90271020) |
| 18 | 14498550 | PLUG (#14498550) |
| 19 | 18766850 | PLUG (#18766850) |
| 20 | 90706584 | O RING (#90706584) |
