1988 1990 California III Full Fairing 1000 Fairing
| Position | Part Number | Description |
|---|---|---|
| 1 | 295754601 | #01 Top fairing (#295754601) |
| 1 | 29575470 | BARE FAIRING (#29575470) |
| 1 | 29575471 | FAIRING C (#29575471) |
| 2 | 29577260 | WINDSHIELD CALIFORNIA III FULLDRESS 89 ORIGINAL (#29577260) |
| 3 | 29942360 | DECAL SILVER (#29942360) |
| 4 | 17769861 | MIRROR (#17769861) |
| 5 | 29579360 | RH POCKET (#29579360) |
| 6 | 29576260 | RH SIDE LID (#29576260) |
| 7 | 29579460 | GASKET (#29579460) |
| 8 | 29576360 | LH SIDE LID (#29576360) |
| 10 | 29573460 | LOCK BEZEL NUT (#29573460) |
| 11 | 95021019 | LOCK WASHER (#95021019) |
| 12 | 92608618 | NUT A (#92608618) |
| 13 | 29739460 | LOCK LEVER (#29739460) |
| 14 | 29468748 | NUT A (#29468748) |
| 15 | 29579660 | LH POCKET A (#29579660) |
| 16 | 29574760 | BAR GUARD (#29574760) |
| 17 | 295703601 | #17 RH side panel (#295703601) |
| 17 | 29570370 | RH SIDE FRAME (#29570370) |
| 17 | 29570371 | RH LOWER SIDE C (#29570371) |
| 18 | 29478160 | RH AIR INTAKE B (#29478160) |
| 19 | 29572160 | SUPPORT (#29572160) |
| 20 | 98074316 | BOLT (#98074316) |
| 21 | 95001206 | WASHER (#95001206) |
| 22 | 92602206 | NUT (#92602206) USE STHN6MM |
| 23 | 295704601 | #23 LH side panel (#295704601) |
| 23 | 29570470 | L H FRAME (#29570470) |
| 23 | 29570471 | LH LOWER SIDE C (#29570471) |
| 24 | 29478260 | AIR INTAKE LH (#29478260) |
| 25 | 29578661 | SUPPORT C (#29578661) |
| 26 | 29570860 | SUPPORT BEAM A (#29570860) |
| 27 | 17451750 | PLATE (#17451750) |
| 28 | 98230816 | SCREW (#98230816) |
| 29 | 61270300 | WASHER (#61270300) |
| 30 | 98230612 | ALLEN SCREW (#98230612) |
| 31 | 61013800 | SPRING WASHER (#61013800) |
| 33 | 92660601 | CAGE NUT (#92660601) |
| 34 | 98230620 | ALLEN BOLT (#98230620) |
| 35 | 29577860 | PLASTIC WASHER (#29577860) |
| 36 | 92630107 | NUT NYLOC (#92630107) |
| 37 | 29573860 | GROMMET (#29573860) |
| 38 | 95100120 | WASHER (#95100120) use 95105320 |
| 39 | 23922210 | FASTENER (#23922210) |
| 40 | 29578260 | SUPPORT RH (#29578260) |
| 41 | 29578360 | SUPPORT LH A (#29578360) |
| 43 | 29574260 | RH LOWER BRACKET (#29574260) |
| 44 | 29574360 | LH LOWER BRACKET (#29574360) |
| 45 | 29736961 | GAS CAP W/LOCK & KEY (#29736961) |
