1989 1994 S 1000 Front Rear Mudguards
| Position | Part Number | Description |
|---|---|---|
| 1 | 14434470 | FRONT FENDER B (#14434470) |
| 2 | 14434670 | FENDER BRACE A 1000 S 1993 (#14434670) |
| 3 | 98270627 | SCREW (#98270627) |
| 4 | 95000206 | WASHER (#95000206) |
| 5 | 92630206 | NUT (#92630206) |
| 6 | 98054418 | BOLT (#98054418) |
| 7 | 95000208 | WASHER (#95000208) |
| 8 | 14437070 | REAR FENDER (#14437070) |
| 9 | 144391701 | #09 Mudguard support (#144391701) |
| 10 | 14438700 | SPLASH GUARD (#14438700) |
| 11 | 93180080 | PLUG (#93180080) |
| 12 | 98054320 | BOLT (#98054320) |
| 13 | 98054335 | BOLT (#98054335) |
| 14 | 91180712 | SPACER A (#91180712) |
| 15 | 93110060 | RUBBER WASHER (#93110060) |
| 16 | 95100141 | WASHER (#95100141) |
| 17 | 92630106 | NUT USE 92630707 (#92630106) |
| 18 | 93301313 | BRACKET (#93301313) |
| 19 | 98326013 | SCREW (#98326013) |
| 20 | 95100137 | WASHER (#95100137) |
| 22 | 98822425 | SCREW (#98822425) |
| 23 | 95004208 | WASHER (#95004208) |
| 24 | 92781081 | CAP NUT (#92781081) USE STCN8MM |
| 25 | 14464370 | REAR GRIP (#14464370) |
| 26 | 17450300 | SAFETY BAR RH (#17450300) |
| 27 | 17450400 | SAFETY BAR LH (#17450400) |
| 28 | 98054420 | BOLT (#98054420) |
| 29 | 17451750 | PLATE (#17451750) |
