1989 1994 S 1000 Front Wheel Spokes
| Position | Part Number | Description |
|---|---|---|
| 1 | 14610371 | FRONT WHEEL WIRE 1000 S (#14610371) |
| 2 | 28611633 | SPOKE LONG (#28611633) |
| 3 | 28611733 | NIPPLES (#28611733) |
| 4 | 12616101 | BALANCE WEIGHT (#12616101) |
| 4 | 12616102 | BALANCE WEIGHT 20 GRAMS (28 GRAMS=1 OZ) (#12616102) |
| 4 | 12616103 | BALANCE WEIGHT (#12616103) |
| 5 | 14620370 | FLANGE A (#14620370) |
| 6 | 29615260 | SPACER (#29615260) |
| 7 | 92204220 | BEARING (#92204220) |
| 8 | 90272047 | CIRCLIP (#90272047) |
| 9 | 28613670 | BRAKE DISC B (#28613670) |
| 10 | 14613770 | Inner brake disk (#14613770) |
| 11 | 98250825 | BOLT A (#98250825) |
| 12 | 28613560 | BRAKE BUSHING (#28613560) |
| 13 | 28618860 | CUP SPRING (#28618860) |
| 14 | 90271022 | CIRCLIP A (#90271022) |
| 15 | 98052480 | SCREW (#98052480) |
| 16 | 14615901 | WASHER (#14615901) |
| 17 | 92630508 | NUT (#92630508) |
| 18 | 14614170 | FRONT AXLE A (#14614170) |
| 19 | 14615670 | SPACER A (#14615670) |
| 20 | 95004217 | WASHER (#95004217) |
| 21 | 29616450 | NUT A (#29616450) |
