1989 1994 S 1000 Rear Wheel Spokes
| Position | Part Number | Description |
|---|---|---|
| 1 | 28630633 | WHEEL 1000 S (#28630633) |
| 2 | 28631133 | SPOKE-SHORT (#28631133) |
| 3 | 28611633 | SPOKE LONG (#28611633) |
| 4 | 28611733 | NIPPLES (#28611733) |
| 5 | 12616101 | BALANCE WEIGHT (#12616101) |
| 5 | 12616102 | BALANCE WEIGHT 20 GRAMS (28 GRAMS=1 OZ) (#12616102) |
| 5 | 12616103 | BALANCE WEIGHT (#12616103) |
| 6 | 30632460 | DISC SPACER A (#30632460) |
| 7 | 92204220 | BEARING (#92204220) |
| 8 | 90272047 | CIRCLIP (#90272047) |
| 9 | 28613670 | BRAKE DISC B (#28613670) |
| 10 | 28613770 | INNER BRK PLATE A (#28613770) |
| 11 | 28613560 | BRAKE BUSHING (#28613560) |
| 12 | 28618860 | CUP SPRING (#28618860) |
| 13 | 90271022 | CIRCLIP A (#90271022) |
| 14 | 98230825 | SCREW (#98230825) |
| 15 | 28633300 | R WHEEL AXLE (#28633300) |
| 16 | 98622430 | SCREW (#98622430) |
| 17 | 14615901 | WASHER (#14615901) |
| 18 | 14634051 | SPACER (#14634051) |
| 19 | 17633550 | CUP (#17633550) |
| 20 | 01336800 | RUBBER BLOCK (#01336800) |
| 21 | 90706490 | O RING (#90706490) |
| 22 | 14335203 | HUB (#14335203) |
| 23 | 14335303 | RING (#14335303) |
| 24 | 17335950 | LOCK PLATE (#17335950) |
| 25 | 95021106 | WASHER, WAVE (#95021106) |
| 26 | 98054312 | BOLT (#98054312) |
| 27 | ||
| 28 | 14634400 | RING (#14634400) |
| 29 | 92602316 | AXLE NUT (#92602316) |
