1990 1992 Sp 750 Front Rear Mudguards
| Position | Part Number | Description |
|---|---|---|
| 1 | 274344201 | #01 Front mudguard blank (#274344201) |
| 1 | 31434340 | #01 Front mudguard (#31434340) |
| 1 | 31434341 | #01 Front mudguard (#31434341) |
| 2 | 98230845 | ALLEN BOLT (#98230845) |
| 3 | 27436920 | #02 Splash guard (#27436920) |
| 4 | 28659740 | GROMMET (#28659740) |
| 5 | 27438635 | REAR PANEL A (#27438635) |
| 6 | 98054320 | BOLT (#98054320) |
| 7 | 93110060 | RUBBER WASHER (#93110060) |
| 8 | 95000206 | WASHER (#95000206) |
| 9 | 95100141 | WASHER (#95100141) |
| 10 | 92630106 | NUT USE 92630707 (#92630106) |
| 11 | 19705900 | PLUG (#19705900) |
| 12 | 27437085 | FENDER REAR A (#27437085) |
| 13 | 95004206 | WASHER (#95004206) |
| 14 | 93110082 | RUBBER WASHER (#93110082) |
| 16 | 31474340 | #16 Rear headlight supp. (#31474340) |
| 17 | 91551085 | RUBBER BLOCK USE 9155 1086 (#91551085) |
| 18 | 91180607 | SPACER (#91180607) |
| 19 | ||
| 20 | 234726301 | #20 Rear fairing (#234726301) |
| 20 | 31472640 | #20 Rear fairing (#31472640) |
| 20 | 31472641 | #20 Rear fairing (#31472641) |
| 21 | 98290516 | BOLT (#98290516) |
| 23 | 27462085 | #23 Covers assy (#27462085) |
| 24 | 92602205 | NUT (#92602205) |
| 25 | 95000205 | WASHER (#95000205) |
| 26 | 92660501 | CAGE NUT (#92660501) |
| 27 | ||
| 28 | 27468720 | LOCK (#27468720) |
| 29 | 98622214 | SCREW (#98622214) |
| 31 | 91551092 | #04 Grommet (#91551092) |
| 32 | 90706092 | O RING (#90706092) |
| 33 | 28436460 | BUSHING A (#28436460) |
| 34 | 31436415 | SPACER A (#31436415) |
| 35 | 23464430 | #35 Pillion grab bar (#23464430) |
| 36 | 31900015 | #38 Operator's handbook (#31900015) |
| 37 | 28929940 | TOOL KIT 14929955 (#28929940) |
| 38 | 28912740 | SHOCK ADJ TOOL (#28912740) |
| 39 | 90716057 | FAIRING O RING (#90716057) |
| 40 | 95100059 | WASHER (#95100059) |
| 41 | 92630105 | NUT (#92630105) |
| 42 | 98052220 | BOLT (#98052220) |
