1990 1993 California III Injected 1000 Air Filter
| Position | Part Number | Description |
|---|---|---|
| 1 | 29114060 | AIR FILTER BOX (#29114060) |
| 2 | 28113660 | AIR FILTER (#28113660) |
| 3 | 29113560 | AIRBOX COVER A (#29113560) |
| 4 | 29114460 | AIR TUBE A (#29114460) |
| 5 | 93305060 | CLAMP (#93305060) |
| 6 | 29727060 | PRESSURE SENSOR (#29727060) |
| 7 | 98054318 | BOLT (#98054318) |
| 8 | 91180608 | SPACER (#91180608) |
| 9 | 95004206 | WASHER (#95004206) |
| 10 | 92630106 | NUT USE 92630707 (#92630106) |
| 11 | 29729361 | AIR TEMP SENSOR (#29729361) |
| 12 | 29116960 | AIRBOX FITTING (#29116960) |
| 13 | 90706076 | O RING (#90706076) |
| 14 | 29115860 | AIRBOX FITTING (#29115860) |
| 15 | 90706060 | O RING (#90706060) |
| 16 | 00823942070 | Pipe (#00823942070) |
| 17 | 28157950 | BREATHER PIPE CLAMP (#28157950) |
| 18 | 98622218 | ALLEN BOLT (#98622218) |
| 19 | 95000205 | WASHER (#95000205) |
| 20 | 00823942080 | Breather pipe (#00823942080) |
| 21 | 00823946060 | Breather pipe (#00823946060) |
| 22 | 93704140 | Nut (#93704140) |
| 23 | 95004213 | WASHER (#95004213) |
| 24 | 29402660 | BRACKET A (#29402660) |
| 25 | 14115401 | BRACKET (#14115401) |
