1992 1997 Quota 1000 Drive Shaft
| Position | Part Number | Description |
|---|---|---|
| 1 | 30060085 | Cylinder with piston assy., RH (#30060085) |
| 1 | 30060110 | RH CYL/PISTON A C (#30060110) |
| 2 | 30060111 | LH CYL/PISTON A C (#30060111) |
| 2 | 30060185 | Cylinder with piston assy., LH (#30060185) |
| 3 | 30060410 | PISTON - BARE (#30060410) |
| 4 | 18060601 | RING SET USE MC 128 (#18060601) |
| 5 | 14060760 | PISTON RING-TOP A (#14060760) |
| 6 | 18060950 | PISTON RING (#18060950) |
| 7 | 14061060 | OIL RING (#14061060) |
| 8 | 28061260 | WRIST PIN (#28061260) |
| 9 | 27061385 | CIRCLIP (#27061385) |
| 10 | 14020865 | BASE GASKET (#14020865) |
| 11 | 90706094 | O RING-VITON (#90706094) |
| 12 | 12021800 | BOLT (#12021800) |
| 13 | 12021700 | BOLT-ROD (#12021700) |
| 14 | 30061500 | CON ROD ASSY C (#30061500) |
| 15 | 30062260 | CON ROD BOLT (#30062260) |
| 16 | 91112128 | BUSH-CON ROD (#91112128) |
| 17 | 30062000 | ROD BRG HALF STD (#30062000) USE 01062030 |
| 17 | 30062001 | HALF BEARING 1ST (#30062001) |
| 17 | 30062002 | ROD BRG 2ND (#30062002) |
| 17 | 30062003 | ROD BRG 3RD (#30062003) |
| 18 | 29064161 | #01 Drive shaft (#29064161) |
| 19 | 12065400 | CRANK PLUG (#12065400) |
| 20 | 29067060 | FLYWHEEL FI NLA USE 03067030 (#29067060) |
| 21 | 12067701 | SCREW (#12067701) use 597150 |
| 22 | 14615901 | WASHER (#14615901) |
| 23 | 17067900 | RING GEAR (#17067900) |
| 24 | 98054420 | BOLT (#98054420) |
| 25 | 92731090 | NUT (#92731090) |
