1992 1997 Quota 1000 Oil Pump
| Position | Part Number | Description |
|---|---|---|
| 1 | 30146400 | HIGH VOLUME OIL PUMP HD (#30146400) |
| 2 | 30147700 | PUMP GEAR HD (#30147700) |
| 3 | 98622430 | SCREW (#98622430) |
| 4 | 13148300 | KEY SQUARE STOCK (#13148300) |
| 5 | 92252210 | BEARING (#92252210) |
| 6 | 95120085 | WASHER (#95120085) |
| 7 | 92602308 | NUT (#92602308) |
| 8 | 17768750 | OIL SENDER (#17768750) |
| 9 | 12006400 | ALUM CRUSH WASHER (#12006400) |
| 10 | 14152200 | FILTER SCREEN (#14152200) |
| 11 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 12 | 95187006 | STOP PLATE (#95187006) |
| 13 | 14153000 | UFI OIL FILTER #14153000 (#14153000 ) |
| 13 | 30153000 | OIL FILTER #30153000 UFI 23.287.00 (#30153000) |
| 14 | 03158200 | OIL VALVE ASSY A (#03158200) |
| 15 | 10158701 | VALVE HOUSING (#10158701) |
| 16 | 12150900 | PISTON (#12150900) |
| 17 | 94321072 | SPRING (#94321072) |
| 18 | 12150700 | BOTTOM PLATE (#12150700) |
| 19 | 12159000 | PLUG (#12159000) |
| 20 | 95100523 | WASHER (#95100523) |
| 21 | 14158800 | BOTTOM CUP (#14158800) |
| 22 | 01153600 | OIL FEED LINE USE 01153602 (#01153600) |
| 23 | 25656102 | GASKET (#25656102) |
| 24 | 95990037 | BANJO BOLT (#95990037) |
| 25 | 12154200 | OIL LINE CRUSH WASHER (#12154200) |
| 26 | 01007200 | VENT PIPE A (#01007200) |
| 27 | 12007600 | OIL RETURN GASKET (#12007600) |
| 28 | 98054320 | BOLT (#98054320) |
| 29 | 95120065 | WASHER (#95120065) |
| 30 | 28150560 | CHECK VALVE (#28150560) |
| 31 | 30157430 | VENT HOSE A (#30157430) |
| 32 | 12157800 | BAND OR CLAMP (#12157800) |
| 33 | 28153960 | CONNECTOR A (#28153960) |
| 34 | 00823942070 | Pipe (#00823942070) |
| 35 | 93305017 | HOSE CLAMP (#93305017) |
| 36 | 28157950 | BREATHER PIPE CLAMP (#28157950) |
| 37 | 28157050 | PIPING (#28157050) |
| 39 | 14003800 | FILLER CARTRIDG (#14003800) |
| 39 | 30003800 | FITTING (#30003800) |
