1993 1994 Strada 1000 Front Lh Rear Brake System
| Position | Part Number | Description |
|---|---|---|
| 1 | 28652301 | CALIPER RH (#28652301) |
| 2 | 28657560 | BRAKE HOSE (#28657560) |
| 3 | 91551131 | GROMMET (#91551131) |
| 4 | 95990028 | SCREW (#95990028) |
| 5 | 25656100 | WASHER, ALUMINUM (#25656100) |
| 6 | 98622525 | BOLT (#98622525) |
| 7 | 95129180 | WAVE WASHER (#95129180) |
| 9 | 28658760 | BRAKE PIPE (#28658760) |
| 10 | 17659650 | TUBE (#17659650) |
| 11 | 28659750 | BRKTS (#28659750) |
| 12 | 91551120 | GROMMET (#91551120) |
| 14 | 17658360 | CLAMP (#17658360) |
| 15 | 17658260 | RUBBER RING (#17658260) |
| 16 | 28658840 | BRAKE HOSE (#28658840) |
| 17 | 17659260 | BLEEDER SCREW KIT (#17659260) |
| 20 | 23943510 | CHROME PLUG (#23943510) |
| 21 | 28653001 | CALIPER (#28653001) |
| 22 | 28635800 | BRACKET (#28635800) |
| 23 | 28654601 | (#28654601) |
| 24 | 17654760 | COVER (#17654760) |
| 25 | 14659000 | CALIPER KIT (#14659000) |
| 26 | 14659100 | BRAKE PINS KIT 2 PER BAG (#14659100) |
| 27 | 95100332 | SHIM 0.5 MM (#95100332) |
| 27 | 95100333 | SHIM 0.8 MM (#95100333) |
| 28 | 98280410 | SCREW (#98280410) |
| 29 | 92630104 | NUT (#92630104) |
| 30 | 98054316 | BOLT (#98054316) USE STHB6X16 |
| 31 | 95000206 | WASHER (#95000206) |
| 32 | 92630106 | NUT USE 92630707 (#92630106) |
