1993 1994 Strada 1000 Ignition Unit I
| Position | Part Number | Description |
|---|---|---|
| 1 | 28704552 | BATTERY (#28704552) |
| 2 | ||
| 3 | 14705500 | BATTERY STRAP, REAR (#14705500) |
| 4 | 28704850 | STRAP (#28704850) |
| 5 | 93180220 | TIMING HOLE PLUG (#93180220) |
| 6 | 29721450 | DIGIPLEX IGNITION UNIT (#29721450) |
| 7 | 98054320 | BOLT (#98054320) |
| 8 | 61013800 | SPRING WASHER (#61013800) |
| 9 | 92660601 | CAGE NUT (#92660601) |
| 10 | 29722140 | IGN HARNESS A (#29722140) |
| 11 | 30732510 | RELAY (#30732510) |
| 12 | 98622216 | ALLEN BOLT (#98622216) |
| 13 | 95100060 | WASHER (#95100060) |
| 14 | 91180607 | SPACER (#91180607) |
| 15 | 91551073 | GROMMET A (#91551073) |
| 16 | 95000205 | WASHER (#95000205) |
| 17 | 92630105 | NUT (#92630105) |
| 18 | 29108140 | HOSE ASSY (#29108140) |
| 19 | 29721660 | SENSOR IGNITION CAM CRANK (#29721660) |
| 20 | 90706141 | O RING (#90706141) USE 847180 |
| 21 | 29722760 | SENSOR GASKET (#29722760) |
| 22 | 98290508 | SCREW (#98290508) |
| 23 | 95004205 | WASHER (#95004205) |
| 24 | 30716500 | IGNITION COIL (#30716500) |
| 25 | 29407440 | COIL BRACKET A (#29407440) |
| 26 | 98610130 | ALLEN BOLT (#98610130) |
| 27 | 92630104 | NUT (#92630104) |
| 28 | 14717600 | SPARK PLUG RUBBER BOOT (#14717600) |
| 29 | ||
| 30 | 30717410 | PLUG CAP NGK (#30717410) USE AP8212219 |
| 31 | 30717031 | SPARK PLUG A (#30717031) |
