1993 Sp III 1000 Lower Fairing
| Position | Part Number | Description |
|---|---|---|
| 1 | 305703101 | #01 RH Fairing section (#305703101) |
| 1 | 30570311 | RH LWR GREY (#30570311) |
| 1 | 30570312 | RH LWR GREEN C (#30570312) |
| 2 | 30576210 | RH CONTAINER A (#30576210) |
| 3 | 91551085 | RUBBER BLOCK USE 9155 1086 (#91551085) |
| 4 | 99210316 | SCREW (#99210316) |
| 5 | 00823932085 | outline (#00823932085) |
| 6 | 305704101 | #06 LH Fairing section (#305704101) |
| 6 | 30570411 | LH LWR GREY C (#30570411) |
| 6 | 30570412 | LH LWR GREEN C (#30570412) |
| 7 | 30576310 | LH CONTAINER A (#30576310) |
| 8 | 30941710 | USE 19941715 (#30941710) |
| 9 | 30579110 | RH BRACKET A (#30579110) |
| 10 | 30579210 | LH BRACKET (#30579210) |
| 11 | 98610335 | BOLT (#98610335) |
| 12 | 95001206 | WASHER (#95001206) |
| 13 | 91180605 | SPACER (#91180605) |
| 14 | 305705101 | #14 Pillar (#305705101) |
| 14 | 30570511 | LWR CTR GREY C (#30570511) |
| 14 | 30570512 | USE 30570516 (#30570512) |
| 15 | 28579160 | SUPPORT (#28579160) |
| 16 | 98250625 | ALLEN BOLT (#98250625) |
| 17 | 90716067 | SPACER (#90716067) |
| 18 | 98250618 | ALLEN SCREW (#98250618) |
| 19 | 93110060 | RUBBER WASHER (#93110060) |
| 20 | 97250616 | FASTENERS (#97250616) |
| 21 | 98230625 | ALLEN SCREW A (#98230625) |
| 22 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 23 | 29577860 | PLASTIC WASHER (#29577860) |
| 24 | 95100123 | WASHER (#95100123) |
| 25 | 92781065 | NUT A (#92781065) |
| 26 | 18577850 | WASHER (#18577850) |
| 27 | 45212400 | WASHER (#45212400) |
| 28 | 92660601 | CAGE NUT (#92660601) |
