1994 1996 Sport Carburated 1100 Frame
| Position | Part Number | Description |
|---|---|---|
| 1 | 37400105 | FRAME BARE C (#37400105) |
| 2 | 98612635 | ALLEN BOLT (#98612635) |
| 3 | 30217900 | LOCK WASHER (#30217900) |
| 4 | 37415705 | PLATE RH B (#37415705) |
| 5 | 37420105 | SUBFRAME B (#37420105) |
| 6 | 37415805 | PLATE LH B (#37415805) |
| 7 | 30419601 | TIE ROD (#30419601) |
| 8 | 92660112 | NUT NYLOC (#92660112) |
| 9 | 98610540 | BOLT (#98610540) |
| 10 | 19149800 | WASHER (#19149800) USE AP8152220 |
| 11 | 98251035 | ALLEN SCREW (#98251035) |
| 12 | 98251040 | SCREW (#98251040) |
| 13 | 92630110 | NUT (#92630110) |
| 14 | 98072595 | BOLT A (#98072595) |
| 15 | 37202805 | PLATE (#37202805) |
| 16 | 98622420 | ALLEN BOLT A (#98622420) |
| 17 | 95004208 | WASHER (#95004208) |
| 18 | 92630508 | NUT (#92630508) |
| 19 | 98620465 | ALLEN BOLT A (#98620465) |
| 20 | 14615901 | WASHER (#14615901) |
| 21 | 30943400 | HOLE PLUG (#30943400) |
