1996 1999 Sport Injected 1100 Transmission Cage
| Position | Part Number | Description |
|---|---|---|
| 1 | 37200205 | GEARBOX HSG C (#37200205) |
| 2 | 90403547 | FORK SEAL- (#90403547) USE 90403449 |
| 3 | 92256218 | BEARING (#92256218) |
| 4 | 14213803 | PLATE (#14213803) |
| 5 | 98622316 | SCREW (#98622316) |
| 6 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 7 | 92218424 | Input and output bearing for 5 speed (#92218424) |
| 8 | 92234717 | BEARING, ROLLER (#92234717) |
| 9 | 95512081 | PIN (#95512081) |
| 10 | 14201110 | TRANS. COVER GASKET (#14201110) |
| 11 | 37200805 | TRANSMISSION COVER (#37200805) |
| 12 | 90706140 | O RING (#90706140) |
| 13 | 92201417 | BEARING (#92201417) |
| 14 | 14237800 | SCREW (#14237800) |
| 15 | 92602512 | NUT (#92602512) |
| 16 | 98622325 | BOLT CHROME (#98622325) |
| 17 | 98620335 | SCREWS (#98620335) |
| 18 | 12207200 | NEUTURAL SWITCH (#12207200) |
| 19 | 12207700 | NEUTRAL SWITCH GASKET (#12207700) |
| 21 | 98230615 | ALLEN SCREW A (#98230615) |
| 22 | 93180220 | TIMING HOLE PLUG (#93180220) |
| 23 | 12022600 | PLUG (#12022600) |
| 24 | 90706203 | O RING (#90706203) |
| 25 | 95980214 | DRAIN PLUG (#95980214) |
| 26 | 10528900 | CRUSH WASHER, COPPER (#10528900) |
| 27 | 14204955 | PIPE (#14204955) |
| 28 | 00823956080 | OIL BREATHER HOSE (#00823956080) |
| 29 | 94321067 | SPRING (#94321067) |
| 30 | 55234700 | PAWL (#55234700) |
| 31 | 90403548 | TRAN SEAL (#90403548) |
| 32 | 30202300 | GEARBOX MOUNT A (#30202300) |
| 33 | 12154200 | OIL LINE CRUSH WASHER (#12154200) |
| 34 | 95980610 | PLUG (#95980610) |
| 35 | 98822325 | SCREW (#98822325) |
| 36 | 93180245 | RUBBER PLUG (#93180245) |
| 37 | 91181006 | BUSHING A (#91181006) |
| 38 | 98054422 | BOLT (#98054422) |
| 39 | 95004208 | WASHER (#95004208) |
| 40 | 30424660 | HOSE GUIDE (#30424660) |
| 41 | 31003766 | DRAIN PLUG (#31003766) |
| 42 | 37991505 | GEARBOX ASSY A (#37991505) |
