| Position |
Part Number |
Description |
| 1 |
20575420
|
Front fairing, white (#20575420) |
| 1 |
205754201
|
Front fairing, blank (#205754201) |
| 1 |
20575423
|
Front fairing,Carabinieri blue (#20575423) |
| 1 |
20575424
|
Front fairing, Rome blue (#20575424) |
| 2 |
19917535
|
DECAL MOTO GUZZ (#19917535) |
| 3 |
20577220
|
Windscreen (#20577220) |
| 4 |
98230625
|
ALLEN SCREW A (#98230625) |
| 5 |
29577860
|
PLASTIC WASHER (#29577860) |
| 6 |
92630207
|
NUT NYLOC \ (#92630207) |
| 7 |
28769847
|
MIRROR (#28769847) |
| 8 |
98202520
|
SCREW (#98202520) |
| 9 |
95007205
|
WASHER (#95007205) |
| 10 |
20922021
|
v75 decal, gold (#20922021) |
| 11 |
00823931080
|
PVC GASKET (#00823931080) |
| 12 |
20579320
|
RH compartment (#20579320) |
| 13 |
20579620
|
LH compartment (#20579620) |
| 14 |
20576220
|
RH cover, white (#20576220) |
| 14 |
205762201
|
RH cover, blank (#205762201) |
| 14 |
20576223
|
RH cover, Carabinieri blue (#20576223) |
| 14 |
20576224
|
RH cover, Rome blue (#20576224) |
| 15 |
20576320
|
LH cover, white (#20576320) |
| 15 |
205763201
|
LH cover, blank (#205763201) |
| 15 |
20576323
|
LH cover, Carabinieri blue (#20576323) |
| 15 |
20576324
|
LH cover, Rome blue (#20576324) |
| 16 |
30468700
|
LOCK ASSY (#30468700) |
| 17 |
30735500
|
IGNITION KEY BLANK (#30735500) |
| 18 |
95021019
|
LOCK WASHER (#95021019) |
| 19 |
92608618
|
NUT A (#92608618) |
| 20 |
95129240
|
WASHER A (#95129240) |
| 21 |
20739420
|
Lock lever (#20739420) |
| 22 |
95100141
|
WASHER (#95100141) |
| 23 |
98084308
|
SCREW (#98084308) |
| 24 |
98326031
|
ALLEN BOLT (#98326031) |
| 25 |
30576100
|
BUSHING (#30576100) |
| 26 |
91551167
|
GROMMET (#91551167) |
| 27 |
92660601
|
CAGE NUT (#92660601) |
| 28 |
20590520
|
Fairing support (#20590520) |
| 28 |
20590521
|
Maintenance SONORA (#20590521) |
| 29 |
98620455
|
SCREW (#98620455) |
| 30 |
95004208
|
WASHER (#95004208) |
| 31 |
92630108
|
NUT 8MM (#92630108) |
| 32 |
98620465
|
ALLEN BOLT A (#98620465) |
| 33 |
98622416
|
SCREW (#98622416) |
| 34 |
14615901
|
WASHER (#14615901) |
| 35 |
20570320
|
RH lower fairing, white (#20570320) |
| 35 |
205703201
|
RH lower fairing, blank (#205703201) |
| 35 |
20570323
|
RH lower fairing,Carabin.blue (#20570323) |
| 35 |
20570324
|
RH lower fairing, Rome blue (#20570324) |
| 36 |
20570420
|
LH lower fairing, white (#20570420) |
| 36 |
205704201
|
LH lower fairing, blank (#205704201) |
| 36 |
20570423
|
LH lower fairing,Carabin.blue (#20570423) |
| 36 |
20570424
|
LH lower fairing, Rome blue (#20570424) |
| 37 |
98326022
|
SCREW (#98326022) |
| 38 |
66478610
|
WASHER (#66478610) |
| 39 |
93231606
|
RUBBER BUSHING (#93231606) |
| 40 |
20450220
|
Front bumper (#20450220) |
| 41 |
98622540
|
SCREW (#98622540) |
| 42 |
98610450
|
SCREW (#98610450) |
| 43 |
61270300
|
WASHER (#61270300) |
| 44 |
17451750
|
PLATE (#17451750) |
| 45 |
19705900
|
PLUG (#19705900) |
