1996 Daytona Racing 1000 Frame Frame
| Position | Part Number | Description |
|---|---|---|
| 1 | 30400100 | FRAME C (#30400100) |
| 2 | 30420200 | FRAME FRONT B (#30420200) |
| 3 | 98610525 | ALLEN BOLT (#98610525) |
| 4 | 19149800 | WASHER (#19149800) USE AP8152220 |
| 5 | 98612635 | ALLEN BOLT (#98612635) |
| 6 | 30217900 | LOCK WASHER (#30217900) |
| 7 | 30202845 | MOUNT GREY A (#30202845) |
| 8 | 98072480 | BOLT A (#98072480) |
| 9 | 98072475 | BOLT A (#98072475) |
| 10 | 30403245 | PLATE GREY A (#30403245) |
| 11 | 98052431 | BOLT (#98052431) |
| 12 | 14615901 | WASHER (#14615901) |
| 13 | 98072597 | BOLT (#98072597) |
| 14 | 92630110 | NUT (#92630110) |
| 15 | 30415745 | PLATE RH GREY B (#30415745) |
| 16 | 30416600 | CROSS TUBE A (#30416600) |
| 17 | 30415845 | PLATE LH GREY B (#30415845) |
| 18 | 92660112 | NUT NYLOC (#92660112) |
| 19 | 30417200 | MOUNTING PLATE (#30417200) |
| 20 | 30419601 | TIE ROD (#30419601) |
| 21 | 30402645 | PLATE LH GREY A (#30402645) |
| 22 | 30402745 | PLATE RH GREY A (#30402745) |
| 23 | 30544045 | SPACER GREY A (#30544045) |
| 24 | 98610540 | BOLT (#98610540) |
| 25 | 98612425 | SCREW (#98612425) |
| 26 | 92630108 | NUT 8MM (#92630108) |
| 27 | 98622430 | SCREW (#98622430) |
| 28 | 98622435 | ALLEN BOLT (#98622435) |
| 29 | 98251035 | ALLEN SCREW (#98251035) |
| 30 | 30943400 | HOLE PLUG (#30943400) |
