1997 1998 Daytona RS 1000 Frame Frame
| Position | Part Number | Description |
|---|---|---|
| - | 98072465 | ALLEN BOLT A (#98072465) |
| 1 | 01400100 | FRAME BARE E (#01400100) |
| 2 | 01420200 | FRAME-FRONT C (#01420200) |
| 3 | 02931600 | PLATE A (#02931600) |
| 4 | 98610525 | ALLEN BOLT (#98610525) |
| 5 | 19149800 | WASHER (#19149800) USE AP8152220 |
| 6 | 01415750 | PLATE RH C (#01415750) |
| 7 | 37420105 | SUBFRAME B (#37420105) |
| 8 | 01415850 | PLATE LH C (#01415850) |
| 9 | 30419601 | TIE ROD (#30419601) |
| 10 | 92660112 | NUT NYLOC (#92660112) |
| 11 | 98610540 | BOLT (#98610540) |
| 12 | 98231030 | ALLEN SCREW (#98231030) |
| 13 | 92630110 | NUT (#92630110) |
| 14 | 98072595 | BOLT A (#98072595) |
| 15 | 37202805 | PLATE (#37202805) |
| 16 | 98622420 | ALLEN BOLT A (#98622420) |
| 17 | 95004208 | WASHER (#95004208) |
| 18 | 92630508 | NUT (#92630508) |
| 19 | 98072460 | ALLEN BOLT A (#98072460) |
| 20 | 14615901 | WASHER (#14615901) |
| 21 | 01517700 | BADGE (#01517700) |
| 22 | 98612535 | SCREW BLACK (#98612535) |
| 23 | 30217900 | LOCK WASHER (#30217900) |
