1997 1999 V 10 Centauro 1000 Drive Shaft
| Position | Part Number | Description |
|---|---|---|
| 1 | 01060150 | CYL & PISTON D (#01060150) |
| 2 | 02060400 | PISTON - BARE (#02060400) |
| 3 | 30060600 | RING SET (#30060600) |
| 4 | 30060700 | PISTON RING (#30060700) |
| 5 | 30060900 | PISTON RING (#30060900) |
| 6 | 30061000 | PISTON RING (#30061000) |
| 7 | 30061241 | WRIST PIN (#30061241) |
| 8 | 90351038 | CIRCLIP (#90351038) |
| 9 | 91111113 | DOWEL (#91111113) |
| 10 | 30020800 | DAYTONA BASE GSKT (#30020800) |
| 11 | 30021700 | STUD LONG (#30021700) |
| 12 | 30061541 | CON ROD ASSY C (#30061541) |
| 13 | 37067905 | RING GEAR B (#37067905) |
| 14 | 37067705 | ALLEN BOLT (#37067705) USE 122675 |
| 15 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 16 | 37062005 | ROD BEARING - HALF (#37062005) |
| 16 | 37062006 | ROD BEARING (#37062006) |
| 16 | 37062007 | ROD BRG 2ND (#37062007) |
| 16 | 37062008 | ROD BRG 3RD (#37062008) |
| 17 | 30064145 | CRANKSHAFT E (#30064145) |
| 18 | 12065400 | CRANK PLUG (#12065400) |
| 19 | 01067000 | FLYWHEEL D (#01067000) |
| 20 | 14615901 | WASHER (#14615901) |
| 21 | 12067701 | SCREW (#12067701) use 597150 |
| 22 | 30062241 | CON ROD BOLT A (#30062241) |
| 23 | 30061841 | BUSHING-CON ROD A (#30061841) |
