1997 1999 V 10 Centauro 1000 Front Brake System
| Position | Part Number | Description |
|---|---|---|
| 1 | 02660100 | MASTER CYLINDER Centauro (#02660100) |
| 2 | 02605600 | BRAKE LEVER (#02605600) |
| 3 | 27664075 | HALF CLAMP (#27664075) |
| 4 | 27604815 | LEVER PIN (#27604815) |
| 5 | 30749860 | MICROSWITCH - (#30749860) |
| 6 | 98200214 | SCREW (98200214) (#98200214) |
| 7 | 92295708 | BALL (#92295708) |
| 8 | 92601002 | NUT (#92601002) |
| 9 | 27661115 | MASTER CYL LID KIT (#27661115) |
| 10 | 02657100 | BRAKE HOSE (#02657100) |
| 10 | 02657110 | BRAKE HOSE (#02657110) |
| 11 | 31656860 | HOSE UNION (#31656860) |
| 12 | 98230635 | ALLEN BOLT A (#98230635) |
| 13 | 61013800 | SPRING WASHER (#61013800) |
| 14 | 91180710 | SPACER (#91180710) |
| 15 | 92660601 | CAGE NUT (#92660601) |
| 16 | 95990028 | SCREW (#95990028) |
| 17 | 25656100 | WASHER, ALUMINUM (#25656100) |
| 18 | 30658800 | BRAKE HOSE RH (#30658800) |
| 19 | 30658801 | BRAKE HOSE LH (#30658801) |
| 20 | 30652302 | CALIPER RH GOLD (#30652302) |
| 21 | 30652202 | CALIPER LH Gold (#30652202) |
| 22 | 98602525 | ALLEN BOLT (#98602525) |
| 23 | 19149800 | WASHER (#19149800) USE AP8152220 |
| 24 | 30654602 | BRAKE PADS SET PR (#30654602) USE FA95 |
| 25 | 30659200 | BLEEDER SCREW KIT (#30659200) |
| 26 | 30659102 | BRAKE PIN KIT (#30659102) |
