1997 1999 V 10 Centauro 1000 Throttle Body
| Position | Part Number | Description |
|---|---|---|
| 1 | 30112501 | THROTTLE BODY C (#30112501) |
| 2 | 30530500 | INJECTOR (#30530500) |
| 3 | 95020104 | WASHER (#95020104) |
| 4 | 98200410 | SCREW (#98200410) |
| 5 | 30530501 | POTENTIOMETER (#30530501) |
| 6 | 30115045 | MANIFOLD RH (#30115045) |
| 7 | 30110500 | CROSS PIECE A (#30110500) |
| 8 | 98230510 | ALLEN BOLT (#98230510) |
| 9 | 95004205 | WASHER (#95004205) |
| 10 | 90706552 | O RING (#90706552) |
| 11 | 30115046 | MANIFOLD LH (#30115046) |
| 12 | 95004206 | WASHER (#95004206) |
| 13 | 98622325 | BOLT CHROME (#98622325) |
| 14 | 95100116 | WASHER (#95100116) |
| 15 | 98310610 | SCREW (#98310610) |
| 16 | 12548401 | CLAMP (#12548401) USE 93306050 |
| 17 | ||
| 18 | ||
| 19 | 01114450 | INTAKE FUNNEL A (#01114450) |
| 20 | 98054216 | SCREW (#98054216) |
| 21 | 29217960 | WASHER (#29217960) |
| 22 | 02118600 | Throttle bracket (#02118600) |
| 22 | 02118601 | Throttle bracket (#02118601) |
| 23 | 30468104 | SCREW (#30468104) |
| 24 | 02999200 | Sparkplug caps kit (#02999200) |
