1997 1999 V 10 Centauro 1000 Transmission Complete II
| Position | Part Number | Description |
|---|---|---|
| 1 | 01350250 | REAR DRIVE E (#01350250) |
| 2 | 30329502 | DRIVESHAFT ASSY C (#30329502) |
| 3 | 98832430 | ALLEN BOLT (#98832430) |
| 4 | 14615901 | WASHER (#14615901) |
| 5 | 30334600 | SPACER A (#30334600) |
| 6 | 28037460 | OUTER VALVE SPRING (#28037460) |
| 7 | 30211700 | CLAMP A (#30211700) |
| 8 | 98612216 | ALLEN BOLT (#98612216) |
| 9 | 29217960 | WASHER (#29217960) |
| 10 | 01358300 | U-JOINT SHROUD A (#01358300) |
| 11 | 37358806 | REACTION ROD B (#37358806) |
| 12 | 30357800 | PIVOT PIN A (#30357800) |
| 13 | 95000210 | WASHER (#95000210) |
| 14 | 19149800 | WASHER (#19149800) USE AP8152220 |
| 15 | 92630410 | NUT A (#92630410) |
| 16 | 37357706 | BOLT FRONT (#37357706) |
| 17 | 95100303 | SPACER A (#95100303) |
| 18 | 92630506 | NUT (#92630506) |
