1997 2000 California EV (v11 EV Usa) 1100 Engine Throttle Body I
| Position | Part Number | Description |
|---|---|---|
| - | 3113460001 | #19 LH cover chromium plated (#3113460001) |
| - | 29113035 | PLATE (#29113035) |
| - | 30113370 | COVER FI RH BLACK PLASTIC (#30113370) |
| 1 | 30112571 | THROTTLE BODY (#30112571) |
| 2 | 1530504 | Injector kit complete 30530570 (#1530504) |
| 3 | ||
| 4 | 29530562 | Throttle Rod (#29530562) |
| 5 | 30114470 | SLEEVE FI (#30114470) |
| 6 | 93305060 | CLAMP (#93305060) |
| 7 | 30114370 | SLEEVE FI RUBBER USE 03114370 (#30114370) |
| 8 | 30115070 | MANIFOLD RH A (#30115070) |
| 9 | 30115071 | MANIFOLD LH (#30115071) |
| 10 | 98622325 | BOLT CHROME (#98622325) |
| 11 | 95004206 | WASHER (#95004206) |
| 12 | 98310610 | SCREW (#98310610) |
| 13 | 95100116 | WASHER (#95100116) |
| 14 | 96506039 | STUD (#96506039) |
| 15 | 61013800 | SPRING WASHER (#61013800) |
| 16 | 92781062 | NUT (#92781062) |
| 17 | 28115560 | MANIFOLD GASKET (#28115560) |
| 18 | 3113360001 | #18 RH cover chromium plated (#3113360001) |
| 19 | 30113470 | COVER FI LH BLACK PLASTIC (#30113470) |
| 20 | 98612110 | SCREW (#98612110) |
| 21 | 95007204 | WASHER (#95007204) |
| 22 | 30118670 | PLATE (#30118670) |
| 23 | 30468104 | SCREW (#30468104) |
