1997 2000 California EV (v11 EV Usa) 1100 Frame Dashboard
| Position | Part Number | Description |
|---|---|---|
| - | 2761500 | #01 Speedometer KMH Borletti (#2761500) |
| - | ||
| - | 2766000 | #18 Socket support (#2766000) |
| - | ||
| - | 92660007 | NUT(#92660007) |
| - | 98230640 | ALLEN BOLT (#98230640) |
| - | 98622312 | SCREW (#98622312) |
| 1 | 2762400 | #01 Speedometer MPH Borletti (#2762400) |
| 2 | 23768310 | ANGLE DRIVE (#23768310) |
| 3 | 2762800 | Reset button (#2762800) USE 02762800 |
| 4 | 97012300000 | SPEEDO CBL BRAIDED STAINLESS STEEL (#97012300000) NLA USE 12760400 |
| 5 | 28762540 | SPEEDO DRIVE ASSY. (#28762540) |
| 6 | 28763340 | DRIVE PINION (#28763340) |
| 7 | ||
| 8 | 93450120 | BULB ALL GLASS (#93450120) |
| 9 | 2767200 | #09 Electronic revolution counter (#2767200) |
| 10 | 2763400 | #10 Column nut 45mm (#2763400) |
| 11 | 2763000 | #11 Stud bolt 40mm (#2763000) |
| 12 | 2764000 | #12 Dashboard lower support (#2764000) |
| 13 | 2762301 | Support rubber part (#2762301) use 02762301 |
| 14 | 2761900 | #14 Tachometer support (#2761900) |
| 15 | 2762000 | #15 Odometer support (#2762000) |
| 16 | 98230510 | ALLEN BOLT (#98230510) |
| 17 | 95129100 | WASHER (#95129100) |
| 18 | 1766031 | #18 Socket support (#1766031) |
| 19 | 93222020 | RUBBER MOUNT (#93222020) USE 93222023 |
| 20 | 91180721 | BUSHING (#91180721) |
| 21 | 98230609 | SCREW (#98230609) |
| 22 | 95100144 | USE 95100141 (#95100144) |
| 23 | 92650106 | Flanged nut (#92650106) |
| 24 | 98622316 | SCREW (#98622316) |
| 25 | 95004206 | WASHER (#95004206) |
| 26 | ||
| 27 | 98872115 | ALLEN BOLT (#98872115) |
| 28 | 2768200 | #28 Gasket (#2768200) |
| 29 | 2768400 | #29 Protection (#2768400) |
| 30 | ||
| 31 | ||
| 32 | 2766500 | #32 Lower cover (#2766500) |
| 33 | 98872110 | ALLEN BOLT (#98872110) |
| 34 | 93450140 | BULB (93450140) (#93450140) USE 164634 |
| 35 | 2768600 | #07 Lampholder (#2768600) USE 02768600 |
| 36 | 1782500 | #06 Main switch steering lock (#1782500) |
| 37 | 98260415 | SCREW (#98260415) |
| 38 | 30735500 | IGNITION KEY BLANK (#30735500) |
| 39 | 17762200 | RUBBER BOOT (#17762200) |
| 40 |
