1998 2001 Nevada Club 750 Supply Carburetor
| Position | Part Number | Description |
|---|---|---|
| 1 | 31112666 | Carburettor RH (#31112666) |
| 1 | 31112672 | Carburettor RH (#31112672) |
| 1 | 31112688 | #01 Carburettor RH PHBH 30 BD (#31112688) |
| 2 | 31112667 | Carburettor LH (#31112667) |
| 2 | 31112673 | Carburettor LH (#31112673) |
| 2 | 31112689 | #02 Carburettor LH PHBH 30 BS (#31112689) |
| 3 | 20115020 | #03 RH intake manifold (#20115020) |
| 4 | 20115021 | #04 LH intake manifold (#20115021) |
| 5 | 19115580 | INTAKE GASKET (#19115580) |
| 6 | 98310610 | SCREW (#98310610) |
| 7 | 95100116 | WASHER (#95100116) |
| 8 | 98622325 | BOLT CHROME (#98622325) |
| 9 | 61013800 | SPRING WASHER (#61013800) |
| 10 | 19114360 | INTAKE SLEEVE USE 31114383 (#19114360) |
| 10 | 31114060 | #10 Sleeve with hole D.15,5 mm (#31114060) |
| 11 | 93305032 | CLAMP (#93305032) |
| 12 | 19114680 | RING (#19114680) |
| 13 | 19114460 | AIR INTAKE (#19114460) |
| 14 | 19718000 | CLAMP (#19718000) |
| 15 | 93305031 | #11 Hose clamp (#93305031) |
