1998 2002 Quota ES 1100 Body
| Position | Part Number | Description |
|---|---|---|
| 1 | 30575425 | FRNG-UNPAINTED B (#30575425) |
| 1 | 30575426 | FRNG-SAND/YELLO D (#30575426) |
| 1 | 30575427 | FRNG-SAND/BLUE D (#30575427) |
| 1 | 30575428 | FRNG-SAND/BRWN D (#30575428) |
| 1 | 30575429 | H-LIGHT FRNG BLACK (#30575429) |
| 1 | 89000303 | HL COWLING RED (#89000303) |
| 2 | 30577230 | WINDSCREEN (#30577230) |
| 3 | 23922210 | FASTENER (#23922210) |
| 4 | ||
| 5 | 93222020 | RUBBER MOUNT (#93222020) USE 93222023 |
| 6 | 95021106 | WASHER, WAVE (#95021106) |
| 7 | 92602206 | NUT (#92602206) USE STHN6MM |
| 8 | 98370616 | BOLT (#98370616) |
| 9 | 29577860 | PLASTIC WASHER (#29577860) |
| 10 | 98370520 | BOLT (#98370520) |
| 11 | 30577800 | NYLON WASHER (#30577800) |
| 12 | 93231605 | FASTENER (#93231605) |
| 13 | 92650005 | NUT (#92650005) |
| 14 | ||
| 15 | 91180608 | SPACER (#91180608) |
| 16 | 30575926 | GRILLE-SAND/PEA B (#30575926) |
| 16 | 30575929 | GRILLE BLACK (#30575929) |
| 16 | 305759301 | #16 Grille, blank (#305759301) |
| 16 | 89000308 | CROSS BRACE RED (#89000308) |
| 17 | 30575830 | RH SCREEN (#30575830) |
| 18 | 30575831 | LH SCREEN (#30575831) |
| 19 | 30570326 | SUPPT RH-SAND/P D (#30570326) |
| 19 | 30570329 | #19 RH front fairing, black (#30570329) |
| 19 | 305703301 | RH FRONT FAIRING, BLANK (#305703301) |
| 19 | 89000309 | RH FRG SIDE RED (#89000309) |
| 20 | 30570426 | #20 LH front fairing, sand (#30570426) |
| 20 | 30570429 | LH SIDE FAIRING BLK QUOTA (#30570429) |
| 20 | 305704301 | SIDE (#305704301) |
| 20 | 89000310 | LH FRG SIDE RED (#89000310) |
| 21 | 30466426 | COWLING SEAT COWL-SAND/ C (#30466426) |
| 21 | 30466429 | TAIL PIECE BLACK (#30466429) |
| 21 | 304664301 | TAIL (#304664301) |
| 21 | 89000307 | TAIL PIECE RED (#89000307) |
| 22 | 30476225 | COVER RH (#30476225) |
| 22 | 30476226 | COVER RH-SAND/Y C (#30476226) |
| 22 | 30476227 | COVER RH (#30476227) |
| 22 | 30476228 | COVER RH (#30476228) |
| 22 | 30476229 | BLACK RH SIDE COVER (#30476229) |
| 22 | 89000304 | RH SIDE CVR RED (#89000304) |
| 23 | 30476325 | COVER LH-BARE (#30476325) |
| 23 | 30476326 | COVER LH (#30476326)YELLOW |
| 23 | 30476327 | COVER LH-(#30476327) |
| 23 | 30476328 | COVER LH-SAND/B C (#30476328) |
| 23 | 30476329 | BLACK LH SIDE COVER (#30476329) |
| 23 | 89000305 | LH SIDE CVR RED (#89000305) |
| 24 | 97250618 | QUICK FASTENER (#97250618) |
| 26 | 28576590 | CLIP A (#28576590) |
| 27 | 30923325 | DECAL SET QUOTA 1100ES (#30923325) |
| 28 | 99210311 | Self-Tap Screw (#99210311) |
| 29 | 30923525 | DECAL A (#30923525) |
| 30 | 30575925 | DECAL RH A (#30575925) |
| 31 | 30575927 | DECAL LH A (#30575927) |
| 32 | 30922525 | DECAL A (#30922525) |
