1998 2002 Quota ES 1100 Exhaust Unit
| Position | Part Number | Description |
|---|---|---|
| 1 | 30120925 | EXH PIPE RH C (#30120925) |
| 2 | 30120926 | EXH PIPE LH C (#30120926) |
| 3 | 98110007 | PLUG (#98110007) |
| 4 | 30109330 | COPPER WASHER (#30109330) |
| 5 | 90718370 | EXHAUST GASKET (#90718370) |
| 6 | ||
| 7 | 01121030 | EXHAUST PIPE FLANGE (#01121030) |
| 7 | 03121000 | EX FLANGE (#03121000) USE 01121030 |
| 8 | 14615901 | WASHER (#14615901) |
| 9 | 92750085 | NUT (#92750085) |
| 10 | 30123930 | EXHAUST CHAMBER OR CROSSOVER QUOTA (#30123930) |
| 11 | 30123400 | EXH CLAMP A (#30123400) |
| 12 | 30123830 | QUOTA MUFFLER BRACKET (#30123830) |
| 13 | 93212520 | VIBRATION DAMPER (#93212520) |
| 14 | 92660208 | FLANGED NUT (#92660208) |
| 15 | 30123025 | MUFFLER USA (#30123025) |
| 15 | 30123030 | MUFFLER QUOTA USE 3012 3025 (#30123030) |
| 16 | 30126930 | CLAMP (#30126930) |
| 17 | 93202208 | #17 Silent-block (#93202208) |
| 18 | 98230840 | ALLEN BOLT A (#98230840) |
| 19 | 92660008 | Nut (#92660008) |
| 20 | 61013800 | SPRING WASHER (#61013800) |
| 21 | 30121930 | MUFFLER GUARD (#30121930) |
| 22 | 98230612 | ALLEN SCREW (#98230612) |
| 23 | 30121625 | EXHAUST GASKET A (#30121625) |
