1998 2002 Quota ES 1100 Handlebar Controls
| Position | Part Number | Description |
|---|---|---|
| 1 | 30600130 | HANDLEBAR QUOTA (#30600130) |
| 2 | 30605525 | CLUTCH LEVER ASSY (#30605525) |
| 3 | 30738826 | RH SWITCH BLOCK (#30738826) |
| 4 | 30603825 | THROTTLE DRUM (#30603825) |
| 5 | 30603525 | GRIP RH A (#30603525) |
| 6 | 30117525 | THROTTLE CABLE (#30117525) |
| 7 | 30602500 | ADJUSTER ASSY (#30602500)USE AP8118348 |
| 8 | 27601815 | LEVER SUPPORT (#27601815) |
| 9 | 27601015 | HALF CLAMP (#27601015) |
| 10 | 27601215 | ALLEN BOLT BLACK (#27601215) |
| 11 | 27604315 | PIVOT SCREW (#27604315) |
| 12 | 92630206 | NUT (#92630206) |
| 13 | 29093071 | CL CABLE (#29093071) |
| 14 | 27663815 | CABLE BOOT (#27663815) |
| 15 | 30132825 | CHOKE CABLE (#30132825) |
| 16 | 27135215 | CHOKE LEVER (#27135215) Use 00H00902661 |
| 18 | 27530594 | WASHER (#27530594) |
| 19 | 27530595 | PLATE A (#27530595) |
| 20 | 92630106 | NUT USE 92630707 (#92630106) |
| 21 | 94321070 | SPRING (#94321070) |
| 22 | 30603025 | GRIP LH A (#30603025) |
| 23 | 01738000 | LH LITE SWITCH (#01738000) |
| 24 | 14769470 | LH MIRROR RECTANGLE (#14769470) |
| 24 | 30769430 | MIRROR LH QUOTA (#30769430) |
| 25 | 14769870 | RH RECTANGLE MIRROR (#14769870) |
| 25 | 30769830 | RH MIRROR (#30769830) |
| 26 | 30900025 | O MANL QUOTA 1100 ES 2000 (#30900025) |
| 27 | 37909905 | TOOL KIT A (#37909905) |
| 30 | 01738020 | SWITCH CENTAURO (#01738020) |
