1999 2001 V 11 Sport mandello 1100 Clutch Pump
| Position | Part Number | Description |
|---|---|---|
| 1 | 01605530 | CLUTCH MASTER CYLINDER (#01605530) |
| 1 | 01605540 | MASTER CYL & LEVER (01605540) (#01605540) |
| 2 | 01605730 | CLUTCH LEVER (#01605730) |
| 2 | 01605740 | Clutch Lever (#01605740) |
| 3 | 30666200 | Pipe (#30666200) |
| 4 | 61108500 | CLIP (#61108500) |
| 5 | 01663530 | CLUTCH RESERVOIR (#01663530) |
| 6 | 01609030 | BRACKET (#01609030) USE 01609060 |
| 7 | 98230613 | Screw (#98230613) |
| 8 | 91551083 | Vibration Damper Pad (#91551083) |
| 9 | 91120610 | CLUTCH MOUNT SLEEVE (#91120610) |
| 10 | 98220620 | screw (#98220620) |
| 11 | 92660604 | Nut (#92660604) |
| 12 | 01606531 | CLUTCH HOSE DARK GREY (#01606531) |
| 13 | 95990028 | SCREW (#95990028) |
| 14 | 25656100 | WASHER, ALUMINUM (#25656100) |
| 15 | 27604815 | LEVER PIN (#27604815) |
| 16 | 01530582 | HALF CLAMP (#01530582) |
| 17 | ||
| 18 | 19659500 | REV KIT (#19659500) |
| 19 | 92601002 | NUT (#92601002) |
| 20 | 92295708 | BALL (#92295708) |
| 21 | 98200214 | SCREW (98200214) (#98200214) |
