1999 2001 V 11 Sport mandello 1100 Front Brake System
| Position | Part Number | Description |
|---|---|---|
| 1 | 01660130 | FRONT MASTER CYLINDER (#01660130) |
| 1 | 01660140 | MASTER CYLINDER FRONT (#01660140) |
| 2 | 01605630 | BR LEVER (#01605630) |
| 2 | 01605640 | FT BRAKE LEVER, Silver (#01605640) |
| 3 | 92295708 | BALL (#92295708) |
| 4 | 27604815 | LEVER PIN (#27604815) |
| 5 | 30749860 | MICROSWITCH - (#30749860) |
| 6 | 01530582 | HALF CLAMP (#01530582) |
| 7 | 19659500 | REV KIT (#19659500) |
| 8 | 30665000 | BRAKE RESERVOIR (#30665000) |
| 9 | 30661100 | RESERVOIR CAP (#30661100) |
| 10 | 01661430 | USE 0166 1460 (#01661430) |
| 11 | 98230613 | Screw (#98230613) |
| 12 | 92601002 | NUT (#92601002) |
| 13 | 98220620 | screw (#98220620) |
| 14 | 91180617 | SPACER (#91180617) |
| 15 | 91551167 | GROMMET (#91551167) |
| 16 | 92660604 | Nut (#92660604) |
| 17 | 00823950050 | TUBE (#00823950050) |
| 18 | 61108500 | CLIP (#61108500) |
| 19 | 95990028 | SCREW (#95990028) |
| 20 | 25656100 | WASHER, ALUMINUM (#25656100) |
| 21 | 01658831 | FRONT BRAKE LINE ASSY DRK GRY (#01658831) |
| 22 | 01652330 | CALIPER R H FRT (#01652330) |
| 23 | 01652230 | CALIPER LH (#01652230) |
| 24 | 98623530 | BOLT (#98623530) |
| 25 | 19149800 | WASHER (#19149800) USE AP8152220 |
| 26 | 98200214 | SCREW (98200214) (#98200214) |
| 27 | 01658230 | RUBBER RING (#01658230) |
| 28 | 01658430 | BRAKE HOSE GUIDE (#01658430) |
| 29 | 98230610 | SCREW (#98230610) |
| 30 | 95001206 | WASHER (#95001206) |
| 31 | 01654630 | BRAKE PADS, PR (#01654630) |
