1999 2001 V 11 Sport mandello 1100 Rear Shock Absorber
| Position | Part Number | Description |
|---|---|---|
| 1 | 01540230 | SWING ARM (#01540230) |
| 2 | 92218418 | Swing arm pivot bearing Spine frame (#92218418) |
| 3 | 37547005 | PIVOT PIN A (#37547005) |
| 4 | 30547800 | CAP NUT (#30547800) |
| 5 | 02550201 | REAR SHOCK (#02550201) |
| 6 | 98053670 | BOLT A (#98053670) |
| 7 | 95004213 | WASHER (#95004213) |
| 8 | 92630513 | NUT A (#92630513) |
| 9 | 92630512 | NUT A (#92630512) |
| 10 | 98610616 | ALLEN BOLT A (#98610616) |
| 11 | 01557930 | Plate (#01557930) |
| 12 | 02107300 | CLAMP A (#02107300) |
| 13 | 98230616 | SCREW (#98230616) |
| 14 | 92630106 | NUT USE 92630707 (#92630106) |
| 15 | 29105860 | RUBBER SLEEVE (#29105860) |
| 16 | 95000206 | WASHER (#95000206) |
