1999 2001 V 11 Sport mandello 1100 Transmission Cage
| Position | Part Number | Description |
|---|---|---|
| 1 | 01200230 | GEAR BOX HOUSING (#01200230) |
| 1 | 01200240 | GEARBOX HOUSING BLK KRNKL (#01200240) |
| 2 | 01200840 | GEARBOX COVER BLACK KRKL (#01200840) |
| 2 | 04200800 | GEAR BOX COVER 6-SPD (#04200800) |
| 3 | 01201330 | Cover (#01201330) |
| 3 | 01201340 | Cover black (#01201340) |
| 4 | 93180220 | TIMING HOLE PLUG (#93180220) |
| 5 | 01205730 | GEAR BOX OIL WINDOW (#01205730) |
| 6 | 01528930 | SEALING WASHER (#01528930) |
| 7 | 19351200 | OIL FILLER CAP (#19351200) |
| 8 | 90706203 | O RING (#90706203) |
| 9 | 31003766 | DRAIN PLUG (#31003766) |
| 10 | 04205500 | STOPPER (#04205500) |
| 11 | 98280620 | Allen Bolt (#98280620) |
| 12 | 04239400 | HOLED SCREW 6-SPD (#04239400) |
| 13 | 12006400 | ALUM CRUSH WASHER (#12006400) |
| 14 | 19206501 | VENT PLUG (#19206501) |
| 15 | 10528900 | CRUSH WASHER, COPPER (#10528900) |
| 16 | 19015020 | BUSH (#19015020) |
| 17 | 90404059 | SEAL (#90404059) |
| 18 | 92234730 | ROLLER BEARING (#92234730) |
| 19 | 92234720 | ROLLER BEARING (#92234720) |
| 20 | 92234017 | BEARING (#92234017) |
| 21 | 04205100 | OIL RETAINER (#04205100) |
| 22 | 92201423 | BEARING (#92201423) |
| 23 | 92201225 | BEARING (#92201225) |
| 24 | 92201141 | BEARING (#92201141) |
| 25 | 90404255 | SEAL-TRANS OUTPUT SHAFT (#90404255) |
| 26 | 98620340 | SCREW (#98620340) |
| 26 | 98620345 | SCREW (#98620345) |
| 27 | 98620445 | SCREW (#98620445) |
| 28 | 98620440 | SCREW (#98620440) |
| 29 | 98620430 | SCREW (#98620430) |
| 29 | 98620435 | SCREW USE 9868 0435 (#98620435) |
| 30 | 98622330 | SCREW (#98622330) |
| 31 | 98620335 | SCREWS (#98620335) |
| 32 | 95000206 | WASHER (#95000206) |
| 33 | 93180245 | RUBBER PLUG (#93180245) |
| 34 | 01991530 | Gear box assy (#01991530) |
| 34 | 01991540 | GEARBOX COMPLETE BLK KRNKL (#01991540) |
