2001 2002 California Ev ev Touring 80 1100 Frame Front Master Cylinder
| Position | Part Number | Description |
|---|---|---|
| - | 95100332 | SHIM 0.5 MM (#95100332) |
| 1 | 3660145 | #01 Front master cylinder (#3660145) |
| 2 | 3605645 | #02 Brake lever (#3605645) |
| 3 | 3664045 | #03 Ubolt (#3664045) |
| 4 | 39663801 | DUST CAP (#39663801) |
| 5 | 3604845 | Lever pin (#3604845) USE 03604845 |
| 6 | ||
| 7 | ||
| 8 | 98230412 | SCREW (#98230412) |
| 9 | 95021104 | WASHER (#95021104) |
| 10 | 3661145 | #10 Pump cover (#3661145) |
| 11 | 95990028 | SCREW (#95990028) |
| 12 | 25656100 | WASHER, ALUMINUM (#25656100) |
| 13 | 3657101 | #13 Flexible pipe (#3657101) |
| 14 | 3658430 | #14 Hose clamp (#3658430) |
| 15 | 3658201 | #09 Ring (#3658201) |
| 16 | ||
| 17 | 98683530 | Bolt, Caliper (#98683530) |
| 18 | 19149800 | WASHER (#19149800) USE AP8152220 |
| 19 | 95100333 | SHIM 0.8 MM (#95100333) |
| 20 | 1654630 | #20 Pads pair (#1654630) |
| 21 | 1659230 | #21 Bleeder+cap (#1659230) |
| 22 | 1659130 | Pins+Caliper springs (#1659130) |
| 23 | 1659131 | #23 Spring (#1659131) |
| 24 | 95008206 | WASHER (#95008206) |
| 25 | 98230618 | ALLEN BOLT A (#98230618) |
