2001 2002 California Ev ev Touring 80 1100 Front Mudguard
| Position | Part Number | Description |
|---|---|---|
| 1 | 03434300 | FRT FNDR BARE C (#03434300) |
| 1 | 03434311 | FRONT FENDER WHITE (#03434311) |
| 1 | 03434313 | FRONT FENDER VINTAGE RED (#03434313) |
| 1 | 03434360 | FRONT FNDR BLACK (#03434360) |
| 2 | 03435200 | MLDG RH FRT A (#03435200) |
| 3 | 03435400 | MLDG LH FRT A (#03435400) |
| 4 | 39922200 | PLATE (#39922200) |
| 5 | 03435300 | MLDG RH REAR (#03435300) |
| 6 | 03435500 | MLDG LH REAR (#03435500) |
| 7 | 03436400 | MOUNTING BLOCK (#03436400) |
| 8 | 03436500 | EYELET (#03436500) |
| 9 | 03436300 | PLATE (#03436300) |
| 10 | 98082225 | Screw (#98082225) |
| 11 | 92787205 | NUT (#92787205) |
| 12 | 03436600 | FORK BRACE (#03436600) |
| 13 | 98370850 | Screw (#98370850) |
| 14 | 95005308 | WASHER M8 (#95005308) |
| 15 | 98350322 | SCREW (#98350322) |
| 16 | 91551010 | GROMMET (#91551010) |
| 17 | 30576100 | BUSHING (#30576100) |
