2001 2002 V 11 Le Mans sport Naked 1100 Frame
| Position | Part Number | Description |
|---|---|---|
| 1 | 01400160 | FRAME (#01400160) |
| 2 | 01420260 | FRONT SUB-FRAME (#01420260) |
| 3 | 02931600 | PLATE A (#02931600) |
| 4 | 98680525 | BOLT (#98680525) |
| 5 | 19149800 | WASHER (#19149800) USE AP8152220 |
| 6 | 01415761 | RH FRAME PLATE RED (#01415761) |
| 6 | 01415762 | RH FRAME PLATE LT GREY (#01415762) |
| 7 | 01420160 | PLATE CONN. FRAME (#01420160) |
| 8 | 01415861 | LH FRAME PLATE RED (#01415861) |
| 8 | 01415862 | LH FRAME PLATE LT GREY (#01415862) |
| 9 | 30419601 | TIE ROD (#30419601) |
| 10 | 92660113 | NUT (#92660113) |
| 11 | 98350540 | Screw M10X40 (#98350540) |
| 12 | 98350530 | Screw M10X30 (#98350530) |
| 13 | 92630110 | NUT (#92630110) |
| 14 | 98082595 | Screw, 10mmx95mm (#98082595) |
| 15 | 28576591 | CLIP (#28576591) |
| 16 | 98210612 | Screw (#98210612) |
| 17 | 01575960 | FRAME COVER (#01575960) |
| 18 | 98680470 | Screw, 8mmx70mm (#98680470) |
| 19 | 30217900 | LOCK WASHER (#30217900) |
| 20 | 92630510 | NUT (#92630510) |
| 21 | 01517700 | BADGE (#01517700) |
| 22 | 98682635 | Bolt (#98682635) |
| 23 | 91120807 | Bushing, 8.2x13x6 (#91120807) |
| 24 | 95008208 | WASHER (#95008208) |
| 25 | 92630108 | NUT 8MM (#92630108) |
