2001 2002 V 11 Le Mans sport Naked 1100 Front Fork I
| Position | Part Number | Description |
|---|---|---|
| 1 | 01490260 | Complete Fork Assy. (LeMans) (#01490260) |
| 1 | 01490285 | Front fork (#01490285) |
| 2 | 01530230 | Steering shock absorber (#01530230) |
| 3 | 98370840 | Screw (#98370840) |
| 4 | 95005308 | WASHER M8 (#95005308) |
| 5 | 91180812 | Spacer (#91180812) |
| 6 | 92630108 | NUT 8MM (#92630108) |
| 7 | 92606408 | Nut (#92606408) |
| 8 | 92700241 | NUT (#92700241) |
| 9 | 30516500 | WASHER (#30516500) |
| 10 | 14517000 | RING DUST SEAL (#14517000) |
| 11 | 14516700 | SHIM (#14516700) |
| 12 | 92249225 | TAPERED ROLLER BRNG (#92249225) |
| 13 | 30513401 | NUT (#30513401) |
| 14 | 23943410 | CHROME PLUG (#23943410) |
| 15 | 01494060 | STEERING STEM & BASE (#01494060) |
| 16 | 01493160 | UPPER TRIPLE CLAMP (#01493160) |
| 17 | 98682430 | Screw (#98682430) |
| 18 | 01490290 | FORK (#01490290) |
| 19 | 01530290 | STEERING DAMPER (#01530290) |
| 20 | AP8116071 | Front fork oil 1 lt. (#AP8116071) |
| 21 | 01526683 | Spring (#01526683) |
| 22 | AP8123975 | Seal kit, Olhins (#AP8123975) |
| 23 | 01517775 | LIMITED EDITION PLATE (#01517775) |
