2001 2002 V 11 Le Mans sport Naked 1100 Fuel Supply
| Position | Part Number | Description |
|---|---|---|
| 1 | 01107231 | FUEL PUMP (#01107231) USE 29107261A |
| 2 | 01107330 | PUMP CLAMP (#01107330) |
| 3 | 01113830 | Hose clamp (#01113830) |
| 4 | 92650106 | Flanged nut (#92650106) |
| 5 | 30609600 | FASTENER A (#30609600) |
| 6 | 98230510 | ALLEN BOLT (#98230510) |
| 7 | 01106130 | Pipe from pump to filter (#01106130) |
| 8 | 30106000 | FUEL FILTER (#30106000) |
| 9 | 29217960 | WASHER (#29217960) |
| 10 | 93306013 | Hose clamp (#93306013) |
| 11 | 01106530 | FUEL LINE (#01106530) |
| 12 | 00823952080 | FUEL HOSE V11 SPORT (#00823952080) |
| 13 | 93306017 | HOSE CLAMP (#93306017) |
| 14 | 29105860 | RUBBER SLEEVE (#29105860) |
| 15 | 98082370 | screw (#98082370) |
| 16 | 95100141 | WASHER (#95100141) |
| 17 | 01112900 | PRESS REG MT (#01112900) |
| 18 | 01112800 | FUEL PRESSURE REGULATOR (#01112800) |
| 19 | 90272037 | CIRCLIP (#90272037) |
| 20 | 30105200 | LOCK NUT (#30105200) |
| 21 | 90714104 | GASKET: PRESSURE REG TO TANK - JACKAL,STONE, ETC (#90714104) |
| 22 | 01101830 | FUEL TAP FLANGE (#01101830) |
| 23 | 90706116 | O RING (#90706116) |
| 24 | 01106161 | HOSE (#01106161) |
| 25 | 01106561 | HOSE (#01106561) |
| 26 | 01704061 | Pump/Regulator Support (#01704061) |
| 27 | 01109661 | PUMP PROTECTOR (#01109661) |
