2001 2002 V 11 Le Mans sport Naked 1100 Headlight Naked
| Position | Part Number | Description |
|---|---|---|
| 1 | 03740540 | HEADLIGHT COMPLETE (#03740540) |
| 1 | 03740545 | LH HEADLIGHT SU D (#03740545) |
| 2 | 02746900 | H/L HARNESS (#02746900) |
| 3 | 01756100 | CONNECTOR 4 WAY (#01756100) |
| 4 | 91551033 | GROMMET A (#91551033) |
| 5 | 93450232 | CAL H/L BULB 60/55 (#93450232) USE 292723 |
| 6 | 01756220 | CONNECTOR 3 WAY (#01756220) |
| 7 | 93450119 | BULB 12V (#93450119) USE 163015 |
| 8 | 01496140 | H/L BRACKET RH BLK (#01496140) |
| 9 | 14439800 | SPACER (#14439800) |
| 10 | 95008208 | WASHER (#95008208) |
| 11 | 01496240 | H/L BRACKET LH BLACK (#01496240) |
| 12 | 98682316 | ALLEN BOLT (#98682316) |
| 13 | 01753440 | FLASHER SPACER (#01753440) |
| 14 | 02750600 | V11 SPORT TURN SIGNAL (#02750600) |
| 15 | 02750601 | V11 SPORT TURNSIGNAL (#02750601) |
| 16 | 93450127 | T/SIG. BULB - CLEAR (#93450127) |
| 17 | 02753700 | TURN SIGNAL LENS AMBER (#02753700) |
| 18 | 98370621 | BOLT (#98370621) |
| 19 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 20 | 31743765 | HORN HIGH A (#31743765) |
| 21 | 31743766 | HORN LOW A (#31743766) |
| 22 | 03740430 | OPTICAL GROUP LENS & RIM ONLY. USA (#03740430) |
| 22 | 03740431 | OPTICAL FOR LH DRIVING (#03740431) use 29740500 |
| 23 | 01781600 | REFLECTOR AMBER USE 1478 1670 (#01781600) |
| 24 | 98350320 | SCREW (#98350320) |
| 25 | 01498430 | SPACER (#01498430) |
| 26 | 98622318 | SCREW (#98622318) |
| 28 | 95000206 | WASHER (#95000206) |
| 29 | 91180606 | Spacer (#91180606) |
| 30 | 03740437 | Cap rear black (#03740437) |
| 31 | 98064425 | BOLT (#98064425) |
| 32 | 01740560 | Headlight (#01740560) |
| 32 | 01740565 | HEADLIGHT O2+ LEMANS (#01740565) |
| 32 | 01740567 | Headlight (#01740567) |
| 33 | 01757660 | INSTR. HARNESS (#01757660) |
| 34 | 01578961 | H/LAMP GASKET (#01578961) |
| 35 | 98350416 | Screw (#98350416) |
| 36 | 95021108 | WASHER (#95021108) |
| 37 | 01496490 | MID PLATE, HEADLIGHT BRK (#01496490) |
