2001 2002 V 11 Le Mans sport Naked 1100 Rear Body
| Position | Part Number | Description |
|---|---|---|
| 1 | 01437030 | REAR FENDER (#01437030) |
| 2 | 98223520 | Screw (#98223520) |
| 3 | 01546340 | PIN COVER RH BLK (#01546340) |
| 3 | 01546363 | RH Pivot Cover (#01546363) |
| 3 | 01546387 | RH pin cover dark grey Guzzi (#01546387) |
| 4 | 01570230 | RH SIDECVR BARE (#01570230) |
| 4 | 01570241 | RH Carbon Fiber Side Cover (#01570241) |
| 4 | 01570261 | RH side panel, grey (#01570261) |
| 4 | 01570262 | RH SIDECVR PEWTER (#01570262) |
| 4 | 01570263 | RH SIDECVR CHROME GREY (#01570263) |
| 4 | 01570286 | RH SIDECVR GUZZI GREY (#01570286) |
| 5 | 01570287 | LH side panel, grey (#01570287) |
| 5 | 01570430 | LH SIDECVR BARE (#01570430) |
| 5 | 01570441 | LH Carbon Fiber Side Cover (#01570441) |
| 5 | 01570461 | LH side panel, grey (#01570461) |
| 5 | 01570462 | LH SIDECVR PEWTER (#01570462) |
| 5 | 01570463 | LH SIDECVR CHROME GREY (#01570463) |
| 6 | 01573960 | RUBBER PAD (#01573960) |
| 7 | 93180710 | VIBRATION DAMPER (#93180710) |
| 8 | 01576131 | bushing (#01576131) |
| 9 | 01577830 | NYLON WASHER (#01577830) |
| 10 | 98370515 | ALLEN SCREW (#98370515) |
| 11 | 01546440 | PIN COVER LH MAT GREY (#01546440) |
| 11 | 01546463 | LH Pivot Cover (#01546463) |
| 11 | 01546487 | Guzzi LH pin cover, grey (#01546487) |
| 12 | 03742030 | BUSHING (#03742030) |
| 13 | 01575940 | DECAL V11 SPORT (#01575940) |
| 14 | 01576060 | SIDE COVER PLATE (#01576060) |
| 15 | 01575975 | (#01575975) |
| 15 | 01576062 | SIDE COVER PLATE (#01576062) |
