2001 2002 V 11 Le Mans sport Naked 1100 Saddle Rear Fairing

Position Part Number Description
1 01460560 SEAT (#01460560)
1 01460585 SEAT (#01460585)
2 02468100 LOCK- SEAT (#02468100)
3 01466430 SEAT COVER BARE (#01466430)
3 01466460 SEAT COVER (#01466460)
3 01466462 SEAT COVER (#01466462)
3 01466475 SEAT COVER MATTE BLK (#01466475)
3 01466486 SEAT COVER ALUM GREY (#01466486)
5 29577860 PLASTIC WASHER (#29577860)
6 01461530 Seat Cover Pillow Ballabio (#01461530)
6 01461585 SEAT COVER PAD (#01461585)
7 92650036 Flanged Nut (#92650036)
8 01573160 Rear Tail, Blank (#01573160)
8 01573161 TAIL SECTION (GUZZI GREY) (#01573161)
8 01573162 TAILPIECE RED (#01573162)
8 01573163 REAR TAIL V11 LEMANS CHAM (#01573163)
8 01573175 TAILPIECE GUZZI GREY (#01573175)
8 01573186 TAILPIECE GUZZI GREY (#01573186)
9 01573760 PLATE (#01573760)
10 66478610 WASHER (#66478610)
11 98370831 Screw (#98370831)
12 28576592 Nut w/ Clip, 6mm (#28576592)
13 91120820 Spacer (#91120820)
14 98230816 SCREW (#98230816)
15 01479660 DOCUMENT HOLDER (#01479660)
16 01900060 OWNERS MANUAL V11 LE MANS & V11 SPORT (#01900060)
17 01462430 LOCK BRACKET (#01462430)
18 93180721 RUBBER BUSHING (#93180721)
19 14217901 LOCK WASHER (#14217901) USE AP8152105
20 98350320 SCREW (#98350320)
21 98250625 ALLEN BOLT (#98250625)
22 98250618 ALLEN SCREW (#98250618)
23 92650006 NUT (#92650006)
24 01468830 SEAT LOCK CABLE (#01468830)
25 02468600 LATCH-SEAT (#02468600)
26 01923360 Decal, V11 Naked (#01923360)
27 01923365 Decal, V11 LeMans 01-02 (#01923365)
28 01736830 LOCKS KIT (#01736830)
29 01923462 LEMANS DECAL (V11) CHROME (#01923462)
30 01923485 DECAL TENNI (#01923485)
31 01923475 DECAL, Scura (#01923475)
32 30970200 PLASTIC COVER A (#30970200)
32 97326090005 V11 BIKE COVER (#97326090005)
33 95005312 Washer, 8.5x24x2 (#95005312)
